3 - 51 3 - 51
MELSEC-Q
3 SPECIFICATIONS
(From previous page)
Write condition *1
Address
(Decimal (Hexadecimal))
CH1 CH2
Settings Range
Default
value
Always
Setting
mode
Disabled
196(C4H) 212(D4H) Scaling value — — — —
197(C5H) 213(D5H) Scaling range upper limit value 0
— —
198(C6H) 214(D6H) Scaling range lower limit value
Refer to Section 3.5.46
0
— —
199(C7H) 215(D7H) Scaling width upper limit value 0
— —
200(C8H) 216(D8H) Scaling width lower limit value
-32768 to 32767
0
— —
201(C9H) 217(D9H) Hold command
0: without command,
1: hold
0
— —
202(CAH) 218(DAH) Command advancing
0: without command,
1: advancing
0
— —
256(100H) 512(200H) Segment monitor — — — —
257(101H) 513(201H) Segment remaining time — — — —
258(102H) 514(202H) Execution times monitor — — — —
259(103H) 515(203H) Pattern end output flag — — — —
260(104H) 516(204H) End status flag — — — —
261(105H) 517(205H) Wait status flag — — — —
262(106H) 518(206H) Hold status flag — — — —
263(107H) 519(207H) Advancing completion flag — — — —
264(108H) 520(208H) Execution pattern monitor — — — —
265(109H) 521(209H) Zone PID monitor — — — —
272(110H) 528(210H) Execution pattern 1 to 3 1 —
—
273(111H) 529(211H) Start mode
0: Zero starting
1: PV starting 1
2: PV starting 2
0 —
—
274(112H) 530(212H) Time scale
0: 0.01s, 1: 0.1s,
2: 1s, 3: 1min
0 —
—
275(113H) 531(213H) Zone 1 upper limit
Input range lower limit to
Zone 2 upper limit
Input range
upper limit
—
—
276(114H) 532(214H) Zone 2 upper limit
Zone 1 upper limit to Zone
3 upper limit
Input range
upper limit
—
—
277(115H) 533(215H) Zone 3 upper limit
Zone 2 upper limit to Zone
4 upper limit
Input range
upper limit
—
—
278(116H) 534(216H) Zone 4 upper limit
Zone 3 upper limit to Zone
5 upper limit
Input range
upper limit
—
—
279(117H) 535(217H) Zone 5 upper limit
Zone 4 upper limit to Zone
6 upper limit
Input range
upper limit
—
—
280(118H) 536(218H) Zone 6 upper limit
Zone 5 upper limit to Zone
7 upper limit
Input range
upper limit
—
—
281(119H) 537(219H) Zone 7 upper limit
Zone 6 upper limit to Input
range upper limit
Input range
upper limit
—
—
(To next page)
*1: Reading is always available regardless of the write conditions. The item of which write condition is set to
"Setting mode" is changeable on setting mode only. Note that changing items during the operation
mode causes a write data error. In addition, it is necessary to turn on the setting change command
(YnB) for changing the setting.
