3 - 53 3 - 53
MELSEC-Q
3 SPECIFICATIONS
(From previous page)
Write condition *1
Address
(Decimal (Hexadecimal))
CH1 CH2
Settings Range
Default
value
Always
Setting
mode
Disabled
Thermocouple
(
)
1 to full-scale
( 0.1 )
—
—
302(12EH) 558(22EH)
Proportional band (P)
setting
Micro voltage
(mV), voltage
(V), current (mA)
1 to 10000
(
0.1%)
100
—
—
303(12FH) 559(22FH) Integral time (I) setting 0 to 32767 ( 0.1s) 400 —
—
304(130H) 560(230H)
Derivative time (D)
setting
0 to 32767 (
0.1s) 100 —
—
305(131H) 561(231H)
Zone 6
Control response
parameter
0: Slow, 1: Normal, 2: Fast 0 —
—
Thermocouple
(
)
1 to full-scale
( 0.1 )
—
—
306(132H) 562(232H)
Proportional band (P)
setting
Micro voltage
(mV), voltage
(V), current (mA)
1 to 10000
(
0.1%)
100
—
—
307(133H) 563(233H) Integral time (I) setting 0 to 32767 ( 0.1s) 400 —
—
308(134H) 564(234H)
Derivative time (D)
setting
0 to 32767 (
0.1s) 100 —
—
309(135H) 565(235H)
Zone 7
Control response
parameter
0: Slow, 1: Normal, 2: Fast 0 —
—
Thermocouple
(
)
1 to full-scale
( 0.1 )
310(136H) 566(236H)
Proportional band (P)
setting
Micro voltage
(mV), voltage
(V), current (mA)
1 to 10000
(
0.1%)
100 —
—
311(137H) 567(237H) Integral time (I) setting 0 to 32767 ( 0.1s) 400 —
—
312(138H) 568(238H)
Derivative time (D)
setting
0 to 32767 (
0.1s) 100 —
—
313(139H) 569(239H)
Zone 8
Control response
parameter
0: Slow, 1: Normal, 2: Fast 0 —
—
(To next page)
*1: Reading is always available regardless of the write conditions. The item of which write condition is set to
"Setting mode" is changeable on setting mode only. Note that changing items during the operation
mode causes a write data error. In addition, it is necessary to turn on the setting change command
(YnB) for changing the setting.
