3 - 59 3 - 59
MELSEC-Q
3 SPECIFICATIONS
(From previous page)
Write condition *1
Address
(Decimal (Hexadecimal))
CH1 CH2
Settings Range
Default
value
Always
Setting
mode
Disabled
474(1DAH) 730(2DAH)
Set value(SV) Input range 0 —
—
475(1DBH) 731(2DBH)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
476(1DCH) 732(2DCH)
Segment 8
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
477(1DDH) 733(2DDH)
Set value(SV) Input range 0 —
—
478(1DEH) 734(2DEH)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
479(1DFH) 735(2DFH)
Segment 9
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
480(1E0H) 736(2E0H)
Set value(SV) Input range 0 —
—
481(1E1H) 737(2E1H)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
482(1E2H) 738(2E2H)
Segment
10
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
483(1E3H) 739(2E3H)
Set value(SV) Input range 0 —
—
484(1E4H) 740(2E4H)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
485(1E5H) 741(2E5H)
Segment
11
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
486(1E6H) 742(2E6H)
Set value(SV) Input range 0 —
—
487(1E7H) 743(2E7H)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
488(1E8H) 744(2E8H)
Segment
12
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
489(1E9H) 745(2E9H)
Set value(SV) Input range 0 —
—
490(1EAH) 746(2EAH)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
491(1EBH) 747(2EBH)
Segment
13
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
492(1ECH) 748(2ECH)
Set value(SV) Input range 0 —
—
493(1EDH) 749(2EDH)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
494(1EEH) 750(2EEH)
Segment
14
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
495(1EFH) 751(2EFH)
Set value(SV) Input range 0 —
—
496(1F0H) 752(2F0H)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
497(1F1H) 753(2F1H)
Segment
15
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
498(1F2H) 754(2F2H)
Set value(SV) Input range 0 —
—
499(1F3H) 755(2F3H)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
500(1F4H) 756(2F4H)
Program pattern 3
Segment
16
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
*1: Reading is always available regardless of the write conditions. The item of which write condition is set to
"Setting mode" is changeable on setting mode only. Note that changing items during the operation
mode causes a write data error. In addition, it is necessary to turn on the setting change command
(YnB) for changing the setting.
To Next Page
