MKS 651C - Page 150

Request and Response Reference A
pp
endix F: Command and Re
q
uest Reference
136
RS-232 Request and Response Summary
(Continued)
Request Message Information Requested Response Message
R18
Softstart rate for set point D
I4
value
where
value
is % of full speed
R19
Softstart rate for set point E
I5
value
where
value
is % of full speed
R20
Softstart rate for analog set
point
I6
value
where
value
is % of full speed
R21
Softstart rate for valve open
I7
value
where
value
is % of full speed
R22
Softstart rate for valve close
I8
value
where
value
is % of full speed
R23
Valve type
J
type
, where
type
equals:
1 = Std 253
2 = Fast 253
3 = 653
R24
Analog set point range
A
range
, where
range
equals:
0 = 5 Volts
1 = 10 Volts
R25
Analog set point type(either
pressure or position)
T0
type
, where
type
equals:
0 = position
1 = pressure
R26
Set point A type (either
pressure or position)
T1
type
, where
type
equals:
0 = position
1 = pressure
R27
Set point B type (either
pressure or position)
T2
type
, where
type
equals:
0 = position
1 = pressure
R28
Set point C type (either
pressure or position)
T3
type
, where
type
equals:
0 = position
1 = pressure
Table 27: RS-232 Request and Response Summary
(Continued on next page)
