Outdoor Station
Technical Specications: KeypadRFID
Functions Keyless access using RFID card and PIN
Interface MxBus
User interfaces
RFID (13.56 MHz, Mifare DESFire EV1), illuminated keys,
acoustic feedback
Inputs 2 galvanically separated inputs (AC/DC, self-powered, up to 48 V)
Outputs 1 insulated relay output (AC/DC, -48 V/60 W/2 A)
Sensors Illumination sensor
Protection class IP65 (DIN EN 60529)
Operating temperature –30 to 50 °C/–22 to 122 °F (DIN EN 50155)
Power supply MxBus
Power consumption typically 1 W
Dimensions (W x H) 99 mm x 99 mm
Technical Specications: Terminals Used On The KeypadRFID
Cable cross-section, solid min. 0.14 mm²/max. 0.5 mm²
Cable cross-section,
exible
min. 0.2 mm²/max. 0.5 mm²
Cable cross-section,
exible, with wire-end
sleeves without plastic
sleeves
min. 0.25 mm²/max. 0.5 mm²
Cable cross-section
AWG/kcmil
min. 24/max. 20
AWG according to UL/CUL min. 26/max. 20
In the case of a power
failure, the access mod-
ule and the door opener
are supplied with power
from the battery of
the MX-DoorMaster
Recommended wire
diameter: 0.6 to 0.8 mm
