50
T26 System Manual Part 1: System Overview
1.4 Accessories
1.4.1 NPA-PoE Set
The MOBOTIX Network Power Adapter Set (NPA-PoE set) is a high-quality, robust, ultra-com-
pact, and – above all – multifunctional PoE injector with three connectors (network, camera/
PoE device, computer) and a universal power supply unit with adapter plugs. The Network
Power Adapter Set supplies the DoorStation and all other PoE devices with power in accor
-
dance with the IEEE 802.3af standard. It is therefore possible to secure the power supply for
distances up to 100 m (300 ) using the network cable. As a result, the DoorStation can be
supplied with PoE power via the adapter and connected directly to a remote station (inte
-
grated crossover function).
This device is especially practical because the supplied power supply unit can be used
around the world by changing the adapters as required in just two simple steps. The “E.U.
version of the NPA-PoE Set is supplied as standard with a European adapter, while the “INT”
version includes four adapters (EU, USA, UK, AUS). Another product benet is the option to
connect to power sources from 12 V to 57 V that are independent of the network, which is
ideal for solar and battery operation of the door station (e.g., in a holiday home).
PoE injector
LAN or POWER
Computer/VoIP
video telephone
or POWER
T26-CamCore (camera module)
RJ45
RJ45
RJ45
LAN/Power
PC/Power
Camera
Integrated and patented
crossover function
LAN/Power
PC/Power
Camera
MX-NPA-PoE-Set-EN and
MX-NPA-PoE-Set-INT incl.
adapters for EU, US, UK and AUS
