T26 System Manual Part 1: System Overview
1.1.5 Info Module
The standard info module provides the option to attach the house or building number and/
or name to the door station. The module is equipped with permanent backlighting using
energy-saving and long-lasting LED technology.
Info eld can be labeled
(behind cover)
Sealing plug
Gasket
MxBus terminal
(power supply for the LED)
99 mm/3.90 in
99 mm/3.90 in
Back with housing cover removed
