33
Outdoor Station
Technical Specications: Info Module
Functions Information for visitors on nameplate (name, street number, etc.)
Interfaces MxBus
User interfaces Backlit, printable foil (UV-protected)
Protection class IP65 (DIN EN 60529)
Operating temperature –30 to 50 °C/–22 to 122 °F (DIN EN 50155)
Power supply MxBus
Power consumption typically 0.2 W
Dimensions (W x H) 99 mm x 99 mm
Technical Specications: Terminals Used on the Info Module
Cable cross-section, xed min. 0.14 mm²/max. 0.5 mm²
Cable cross-section,
exible
min. 0.2 mm²/max. 0.5 mm²
Cable cross-section,
exible, with wire-end
sleeves without plastic
sleeves
min. 0.25 mm²/max. 0.5 mm²
Cable cross-section
AWG/kcmil
min. 24/max. 20
AWG according to UL/CUL min. 26/max. 20
Note on Labeling
You will nd some PDF templates, which you can print out yourself, on the MOBOTIX
website (www.mobotix.com).
Recommended wire
diameter: 0.6 to 0.8 mm
