T26 System Manual Part 1: Installation
2.1.4 Recommendation for Cabling
Depending on the model, the door station and its remote stations require one of the fol-
lowing cabling congurations. Please take note of our cabling recommendations and the
maximum cable lengths. Both the network cable and other cables must be stripped at the
door station ends.
1
Network cable from the Ethernet terminal board behind the camera module
to the switch/injector
• Recommendation: Category 5 (Cat 5) Ethernet installation cable or higher;
Cat 7 cable is designed for 10 Gbit Ethernet (max. future compatibility)
• Max. cable length: 100 m/109.36 yd
2
Two wires from the door station to the MX-DoorMaster for the MxBus connector
• Recommendation: YSTY (telephone) solid wire, core diameter 0.6 to 0.8 mm
• Max. cable length: 50 m/54.68 yd
3
Cables from the MX-DoorMaster to the electric door opener, the door sensor
and the door lock sensor
•
Recommendation: YSTY (telephone) solid wire, core diameter 0.6 to 0.8 mm
• Max. cable length: manufacturer-dependent, max. 50 m/54.68 yd
4
Two wires from the MX-DoorMaster to an additional power supply (for example,
12 V for electronic lock operation)
•
Recommendation: YSTY (telephone) solid wire, core diameter 0.6 to 0.8 mm
• Max. cable length: manufacturer-dependent
5
Two wires from the access module to the 230 V light relay (if present)
•
Recommendation: YSTY (telephone) solid wire, core diameter 0.6 to 0.8 mm
• Max. cable length: manufacturer-dependent
6
Two-wire cable from the Info Module Mx2wire+ to the Mx2wire+ indoor unit (as
an alternative to the outdoor station being directly connected to the network)
• Recommendation: existing, previously laid bell wire (core diameter 0.6 to
0.8 mm)
• Max. cable length: 200 m/218.72 yd (JY, A2Y, YR), 300 m/328.08 yd (NY),
500 m/546.81 yd (Cat 7)
7
Two wires from the door station to the MX-DoorMaster for connecting the
MOBOTIX the protection (for unlocking when exchanging modules)
•
Recommendation: black two-wire cable already tted to the frame, possibly
extended with YSTY (telephone) solid wire, core diameter 0.6 to 0.8 mm
• Max. cable length: 50 m/54.68 yd
The supplied patch cable
is used to connect the
Info Module Mx2wire+
to the camera
NY: installation
cable (not live)
The maximum congura-
tion is specied for these
cabling recommendations
