Mobotix T26 - Page 61

61
Overview: Connection and Wiring Diagrams
Door station
Door
MX-DoorMaster
PoE Switch
(Gegenstellenanschluss)
12 V DC
(for elec. lock)
Power supply
4
Power relay
(e.g. for lamp)
5
7
1 3
2
2
2
2
8
6
2
Cat 5 installation cable or better
max. length: 100 m/109.36 yd
YSTY 0.8 mm (MxBus) – max. length:
50 m/54.68 yd
YSTY 0.8 mm (the protection) – max.
length: 50 m/54.68 yd
Two-wire (alt. network connection)
max. length: 500 m/546.81 yd
YSTY 0.8 mm (e.g. external light)
max. length: manufacturer-dependent
YSTY 0.8 mm (door opener,
Door sensor and door lock sensor –
max. length: 50 m/54.68 yd
YSTY 0.8 mm (for electrical lock) max.
length: manufacturer-dependent
Mx2wire+ indoor unit
2
6
