T26 System Manual Part 1: System Overview
1.1.3 Access Module KeypadRFID
This module is used for keyless and scheduled access to the house or building with an access
PIN or RFID transponder card.
In addition, the KeypadRFID module allows leaving and retrieving messages on the video
mailbox.
Included in delivery:
One admin RFID card
for initial operation and
activating user cards
Included in delivery:
Several user RFID cards
for opening the door and
video mailbox access
Additional cards (admin/
user) can be ordered
from MOBOTIX
I/O terminal
Blindstopfen
Dichtung
MxBus Klemme
Back with housing cover removed
LED (blue)
LED (green, red)
Open door, messages,
doorbell
10-key keypad
+ 2 function keys
99 mm/3.90 in
99 mm/3.90 in
Please note that you can
currently attach
only one
access module
(i.e., either
KeypadRFID or BellRFID)
to an DoorStation.
