Mobotix T26 - Page 43

43
Outdoor Station
Module Frame (Fig. Triple Frame)
Installation of module
Connection of
the protection
Activation of
the protection
333 mm/13.11 in
131 mm/5.16 in
18 mm/0.71 in
Key to release the modules
from the frame (press
upwards; only possible
aer the protection has
been deactivated)
* Ethernet terminal
board ETH Module is
not required when using
Mx2wire+ technology
T26 Modules
MX-DoorMaster,
KeypadRFID,
Info Module/Info Module Mx2wire+
Frame
With integrated
the protection
Housing
On-wall or in-wall
housing
Terminal boarf*
Ethernet terminal
board or Info Module
*Ethernet terminal
board ETH Module is
not required when using
Mx2wire+ technology
