Outdoor Station
Technical Specications: MX-DoorMaster
Functions Security door opener with internal access code memory
Interfaces MxBus (max. 50 m distance to door station)
User interfaces 2 status LEDs, 2 function buttons, integrated speaker (doorbell)
Inputs
2 galvanically separated inputs with shared ground connection (AC/
DC, self-powered – 48 V)
Outputs
1 isolated relay output (AC/DC, 24 V/1 A) or
1 connector for standard door opener (6-12 V AC)
1 output for MOBOTIX the protection (12 V DC)
Protection class IP20 (DIN EN 60529)
Operating temperature –5 to +40°C/+23 to +104°F (DIN EN 50155)
Power supply MxBus
Power consumption typically 1 W
Output max. 10 W
Switch time max. 5 s
Connecting wire thickness Cable cross-section 0.14 to 2.5 mm2, diameter 0.4 to 1.6 mm
Dimensions (W x H x D) 80 mm x 80 mm x 41.5 mm
Note
The battery pack supplies the electrical door opener and, in the event of a power
failure, the access module, which continues to guarantee that the door can be unlocked
multiple times. For installations in living areas, the MX-DoorMaster functions also
as a doorbell.
Supported Door Versions
An electrically-operated standard door opener (6 to 12 V AC, min. nominal resistance 10 ohm,
no support for closed-circuit current function) can be connected directly to the MX-DoorMaster
and powered by its integrated battery pack. It is not necessary to connect an additional
power supply unit.
By integrating an additional power supply unit, door openers with up 24 V AC/DC (max. 1 A)
or a self-locking door lock (e.g., electrical lock or “Mediator”) can be connected.
Max. cable length for
MxBus is 50 m
Thanks to the battery, the door
opener continues to function
in the event of a power failure
