Mobotix T26 - Page 55

55
Overview: Connection and Wiring Diagrams
T26-CamCore Info Module MX-DoorMaster
MxETH
MX +
MX –
MX +
MX –
MX +
MX –
MX +
MX –
IN1 +
IN1 -
IN2 +
IN2 -
COM COM
OUT A
OUT B
MX +
MX –
MX +
MX –
MX +
MX –
IN1 +
IN –
IN2 +
OUT1 +
OUT –
OUT2 +
ETH Module
Door sensor Door lock sensor Door opener (self-powered)
max. 100 m/109.36 yd
max. 50 m/54.68 yd max. 50 m/54.68 yd
Connection of external devices (light relay,
etc.) and 12 V power supply unit
MxDisplay+
e.g. PoE Switch
The protection
(module frame)
KeypadRFID/
BellRFID
