69
Remote Stations and Network Connection
To ensure ease of use, the system should be installed to accommodate people of dierent
heights. The height from the ground to the upper edge of the frame should be at least 1.60 m.
Unlike conventional door cameras, the T26-CamCore with its 180 ° angle of view is also able
to record visitors when they are NOT standing directly in front of the lens. This means that
the door station can be mounted quite exibly, which is particularly useful with wide doors.
The installation can be on-wall, in-wall or using a cavity socket. MOBOTIX provides two
dierent types of housing for these installation methods. The modules and the frame tted
to the housing are suitable for all installation options.
1.60 m/5.25
Door station
(next to door)
Standard 90 °
Door
HD Super 180 °-Panorama
MOBOTIX original image T26 – 1280 x 480
