Remote Stations and Network Connection
The T26 housing (on-wall/in-wall) provides suicient space for cable reserves (see the blue
dashed line in the gure).
The red areas are ‘o-limits areas’. No cables should be placed in this area (risk of damage to
cables when module is mounted).
Cable guide
(dotted blue)
O limits
for cables/wires
The in-wall housing provides
suicient space – there
are no o-limits areas
