Modecom MC-4220 User Manual

www.modecom.eu
86
802.11n WLAN ADSL2+ Router
From the • PortForwarding check ratio, check on Enable
Click • ApplyChanges
Type the Local IP Address for your HTTP Server.•
Enter the range of Local Port for your HTTP Server.•
Select • any from the Interface drop-down list.
Click • Apply
10.0.0.33 80
80
Fieldsontherst
setting block
Description
Enable Port
Forwarding
Check this item to enable the port-forwarding feature.
Protocol There are 3 options available: TCP, UDP and Both.
Enable Check this item to enable this entry.
Local IP Address IP address of your local server that will be accessed by Internet.
Port The destination port number that is made open for this
application on the LAN-side.
Remote IP Address The source IP address from which the incoming trafc is
allowed. Leave blank for all.
External Port The destination port number that is made open for this
application on the WAN-side
Interface Select the WAN interface on which the port-forwarding rule is to
be applied.
Function Button Description
Apply Changes Click to change the setting of default actions to the conguration.
Delete Selected Delete the selected port forwarding rules from the forwarding
table. You can click the checkbox at the Select column to select
the forwarding rule.
Delete All Delete all forwarding rules from the forwarding table.
