June 15, 2005 6815854H01-A
3-76 Theory of Operation: Controller Section
3.14.12Reflashing/Upgrading Firmware
The FLASH IC is the firmware storage IC. Programming this IC is accomplished using one of the
following input paths:
• Two-wire RS-232 directly from a computer’s serial port to the radio’s rear connector data cable
HKN6160
• Two-wire RS-232 through an HKN6183 programming cable at the control head’s 10-pin
accessory port
For a list of all available programming cables, refer to the table below.
NOTE: FLASH IC replacement is not supported as a field repair option. If the FLASH IC is removed,
the radio cannot be reflashed by a customer or radio depot. This is because the FLASH IC
must be hard-boot loaded at the factory to allow the programming of a unique file.
Table 3-14. Programming Cables
Motorola
Part Number
Description Application
HKN6183 Programming Flash Cable Used with Tuner software, Customer Programming
Software (CPS), and FLASHport
RVN4185 Customer Programming Software and
Tuner Software
Programming and radio alignment software on CD
HKN6160 Cable Kit 6’ Dash Mount Data (RS232) Used for programming XTL 1500
If you choose to reflash the radio (reflash the IC), DO NOT interrupt the
process; otherwise, you might corrupt the FLASH IC and need advanced
technical support to revive your radio.
!
C a u t i o n
