Motorola Astro XTL 1500 - Figure 7-69. HUE4039 A Secure USB;RS232;SB9600 VIP Input;Output Schematic

7-86 Schematics, Component Location Diagrams, and Parts Lists: HUE4039A (UHF Range 1) Main Board
June 15, 2005 6815854H01-A
Figure 7-69. HUE4039A Secure USB/RS232/SB9600 VIP Input/Output Schematic
U0605-1
VCC5
U0601-1
0.1uF
VCC5
0.1uF
C0605C0601
U0601-2 U0605-2
U0603-3
U0603-4
4
1
2
4
1
2
GND
5
VCC
3
GND
5
VCC
8
3
12
13
11
9
10
VIP_IN_1_3V
VIP_IN_2_3V
VIP_IN_1_5V
VIP_OUT_1_3V
VIP_OUT_1_5V
VIP_OUT_2_3V
VIP_OUT_2_5V
VIP_IN_2_5V
