700–800 MHz Radio Specifications
GENERAL RECEIVER TRANSMITTER
FCC Designations: AZ492FT5823 Frequency Range: Frequency Range:
700 MHz Band: 764–776 MHz 700 MHz Band:
Temperature Range: 800 MHz Band: 851–870 MHz Repeater Mode: 794–806 MHz
Operating: –30° C to +60° C Talkaround Mode: 764–776 MHz
Storage: –40° C to +85° C Channel Spacing: 12.5 kHz/20 kHz/25 kHz 800 MHz Band:
Repeater Mode: 806–825 MHz
Power Supply: 12 Vdc Negative Ground Only Input Impedance: 50 ohm Talkaround Mode: 851–870 MHz
Battery Drain: (Maximum) Frequency Separation: Full Bandsplit Rated Output Power:
35 W: 764–806 MHz Band: 2***/30 W
Standby @ 13.8 V: 0.7 A Sensitivity: 806–870 MHz Band: 35 W
Receive at Rated Audio @ 13.8 V: 3.0 A 20 dB Quieting:
Transmit @ Rated Power: 25 kHz Channel Spacing: 0.30 µV Channel Spacing: 12.5 kHz/20 kHz/25 kHz
35 W 3.0 A 12 dB SINAD:
25 kHz Channel Spacing: 0.25 µV Output Impedance: 50 ohm
Dimensions (H x W x D)
Dash-Mount Radio: 2.5" x 7.3"x 9.8" Digital Sensitivity**: Frequency Separation: Full Bandsplit
(65 mm x 185 mm x 248 mm) 1% BER (12.5 kHz channel): 0.30 µV
5% BER (12.5 kHz channel): 0.25 µV Frequency Stability*:
Speaker: (excluding mounting bracket) (–30° to +60°C; 25°C Ref.): 1.5 ppm
5.5" x 5.5"x 2.5" Adjacent Channel Selectivity*:
(139.7 mm x 139.7 mm x 63.5 mm) 25 kHz Channel: 80 dB Modulation Limiting*:
12.5 kHz Channel: 65 dB 25 kHz Channel Spacing: ±5.0 kHz
Weight: 12.5 kHz Channel Spacing: ±2.5 kHz
Radio: 6.1 lbs (2.8 kg) Intermodulation*: 80 dB
Speaker: 1.5 lbs (0.7 kg) Modulation Fidelity (C4FM)**:
Spurious Rejection*: 90 dB 12.5 kHz Digital Channel: ±2.8 kHz
Frequency Stability*: FM Hum and Noise*:
(–30° to +60° C; 25° C Ref.): 1.5 ppm 20/25 kHz Channel: –40 dB
12.5 kHz Channel: –34 dB
Audio Output at 3% Distortion*:
7.5 W (External Speaker) Emission (Conducted and Radiated):
3 W (Internal Speaker) –70 dBc/–85 dBc (GNSS)
Audio Sensitivity*:
(For 60% Max. Deviation at 1 kHz):
0.08 V ±3 dB
Audio Response*:
(6 dB/Octave Pre-Emphasis 300 to 3000 Hz):
+1,–3 dB
Audio Distortion*: 2%
Emissions Designators:
8K10F1D, 8K10F1E, 11K0F3E, 16K0F3E, and
20K0F1E
Specifications subject to change without notice.
* Measured in analog mode per TIA/EIA 603 under nominal conditions.
** Measured in digital mode per TIA/EIA IS 102.CAAB.
*** 2 W. itinerant frequencies.
