Flex Cable Pin-Out Lists: List of Flex Cables 8-1
6815854H01-A June 15, 2005
Chapter 8 Flex Cable Pin-Out Lists
8.1 List of Flex Cables
This chapter lists the pin-out assignments for the following flex cables:
•Dash (Table 8-1 on page 8-1)
• Rear Accessory (Table 8-2 on page 8-1)
8.2 Flex Cables
Table 8-1. Dash Flex Cable J5000 to P0401 Pin-Out List
Signal
J5000
70-Pin
(Female)
P0401
50-Pin
(Male)
BUS_PWR_OUT 16 <--> 46
SW B+ 41-46 <--> 17
A+ 33-39 <--> 19, 21
SPKR+ 57-60 <--> 9
SPKR- 61-64 <--> 10
MIC_HI 67 <--> 4
RX_AUDIO 68 <--> 5
IGNITION 40 <--> 20
VIP OUT 1_12v 54 <--> 11
VIP OUT 2_12v 52 <--> 12
BRICK_5V 32 <--> 23
SSI_CLKX 20 <--> 31
SSI_DX 22 <--> 34
SSI_RX 23 <--> 33
SSI_FSX 21 <--> 4
FACT BOOT 17 <--> -
DAMOTE 19 <--> -
VIP OUT 3_12v 53 <--> -
GND Remaining pins <--> 1, 2, 49, 50
Table 8-2. Rear Accessory Flex Cable J2 to P0402 Pin-Out List
Signal
J2
26-Pin
(Female)
P0402
32-Pin
(Female)
GND 1, 14 <--> 1, 2, 14, 31, 32
BUS+ 2 <--> 3
BUS- 3 <--> 5
TX_DCE 4 <--> 7
RX_DCE 5 <--> 9
USB - 6 <--> 13
USB + 7 <--> 11
RESET 8 <--> 4
BUSY 9 <--> 6
RTS_DCE 10 <--> 8
CTS_DCE 11 <--> 10
USB PWR 12 <--> 12
CHAN ACTIVITY 13 <--> 15
Emergency 15 <--> 28
PTT*= AUX PTT 16 <--> 24
ONE WIRE 17 <--> 27
VIP OUT 1 18 <--> 16
VIP OUT 2 19 <--> 17
Spkr + 20 <--> 19, 21
RX_filt_audio 21 <--> 30
MONITOR / HUB 22 <--> 26
Aux_Mic 23 <--> 29
SW B+ 24 <--> 20, 22
IGN 25 <--> 18
Spkr - 26 <--> 23, 25
