Motorola Astro XTL 1500 - ASTRO XTL 1500 700-800 Mhz 10-35 Watt Model Chart

6815854H01-A June 15, 2005
Model Numbering, Charts, and Specifications xxix
ASTRO XTL 1500 700-800 MHz 10-35 Watt Model Chart
M28URS9PW1AN 764–870 MHz
Option Description
W20BX ALT: Keypad Microphone
W382AH ALT: Control Station Palm Microphone
G798AA ADD: Control Station Base Mount
G91AA ADD: Control Station Power Supply
W470AR ADD: External Emergency Footswitch
W688AP ADD: External Emergency Pushbutton
W81AL ADD: Key Lock Mount
W116AN ADD: External Alarm and Relay Cable
B18CL ADD: Auxiliary Speaker Spectra 5 Watt
W484AD ALT: Antenna 3 dB Gain 762-870 MHz
G335AT ADD: Antenna 1/4 Wave 762-870 MHz
G174AA ADD: Antenna 3 dB Low-Profile 762-870 MHz
G175AA ADD: Antenna 3 dB Elevat Feed 762-870 MHz
Item No. Description
X HMN4079_ Keypad Microphone
X HMN1088_ Control Station Desk Microphone
X HLN6925_ Control Station Mount
X HPN4001_ Power Supply
X HLN5113_ Emergency Footswitch
X HLN5131_ Emergency Pushbutton
X HLN6372_ Keylock Mount
X TLN4533_ Relays
X HKN4258_ Cable Relay
X HSN4031_ External 7.5 Watt Speaker
X HAF4013_ Antenna, 3 dB Low Profile 762-870 MHz
X HAF4014_ Antenna, 3 dB Elevat Feed 762-870 MHz
X HAF4016_ Antenna, 1/4 Wave 762-870 MHz
X HAF4017_ Antenna, 3 dB Collinear, 762-870 MHz
X = Item Included
_ = the latest version kit. When ordering a kit, refer to your specific kit for the suffix number.
