7-188 Schematics, Component Location Diagrams, and Parts Lists: HUF4017A (700-800 MHz) Main Board
June 15, 2005 6815854H01-A
VR0418 4813832C75 DIODE ZENER QU O
VR0420 4813830A24 DIODE 11V 5% 225MW
MMBZ5241B_
VR0421 4813830A24 DIODE 11V 5% 225MW
MMBZ5241B_
VR0422 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR0423 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR0424 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR0425 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR0500 4813830A14 DIODE 5.1V 5% 225MW
MMBZ5231B_
VR0501 4813830A24 DIODE 11V 5% 225MW
MMBZ5241B_
VR0950 4813832C77 TRANS SUP .24V HIGH
PWR
VR0951 NOTPLACED 64AM DUMMY PART
NUMBER
Y0100 4809995L05 XTAL QUARTZ 32.768KHZ
CC4V-T1
Y6750 5185143E07 IC 16.8 MHZ REF OSC .8
PPM
* 1085674C03 PASTE/NC-SMQ230
* 5405569Y02 LBL BARCODE APC
* 5405569Y03 LABEL BARCODE
* 1105033S02 RIBBON LABEL LT. PACK
LABEL
* 1105033S13 RIBBON LBL
Reference
Designator
Motorola
Part Number
Description
