Schematics, Component Location Diagrams, and Parts Lists: HUF4017A (700-800 MHz) Main Board 7-187
6815854H01-A June 15, 2005
R6761 0662057M67 RES. CHIP 510 5% 20X40
R6762 0662057M95 RES. CHIP 7500 5%
20X40
R6763 0662057N15 RES. CHIP 47K 5% 20X40
R6764 0662057M78 RES. CHIP 1500 5%
20X40
R6765 0662057M56 RES. CHIP 180 5% 20X40
R6766 0662057M98 RES. CHIP 10K 5% 20X40
R6767 0662057N12 RES. CHIP 36K 5% 20X40
R6768 0662057M95 RES. CHIP 7500 5%
20X40
R6769 0662057M81 RES. CHIP 2000 5%
20X40
R6770 0662057N15 RES. CHIP 47K 5% 20X40
R6774 0662057M62 RES. CHIP 330 5% 20X40
R6775 0662057M98 RES. CHIP 10K 5% 20X40
R6777 0662057M43 RES. CHIP 51 5% 20X40
R6778 0662057M78 RES. CHIP 1500 5%
20X40
R6779 0662057M54 RES. CHIP 150 5% 20X40
R6780 0662057M54 RES. CHIP 150 5% 20X40
R6782 0662057M01 RES. CHIP 0 5% 20X40
R6789 0662057A36 CHIP RES 300 OHMS 5%
R6790 0662057A36 CHIP RES 300 OHMS 5%
R6791 0662057M59 RES CHIP 240 5% 20X40
R6792 0662057M26 RES. CHIP 10 5% 20X40
R6793 0662057M54 RES. CHIP 150 5% 20X40
R6794 0662057M40 RES. CHIP 39 5% 20X40
R6795 0662057M54 RES. CHIP 150 5% 20X40
R6796 0662057M74 RES. CHIP 1000 5%
20X40
R6797 0662057M90 RES. CHIP 4700 5%
20X40
R6798 0662057A36 CHIP RES 300 OHMS 5%
R6799 0662057M61 RES. CHIP 300 5% 20X40
R6800 0662057M32 RES. CHIP 18 5% 20X40
R6801 0683962T44 RES CHIP 62 5-1
R6802 0662057M61 RES. CHIP 300 5% 20X40
R6803 0662057M32 RES. CHIP 18 5% 20X40
R6804 0662057M61 RES. CHIP 300 5% 20X40
R6805 0662057M92 RES. CHIP 5600 5%
20X40
R6806 0662057M74 RES. CHIP 1000 5%
20X40
R6807 0662057C55 CHIP RES 150 OHMS 5%
R6808 0662057M26 RES. CHIP 10 5% 20X40
R6809 0662057M61 RES. CHIP 300 5% 20X40
R6810 0662057M32 RES. CHIP 18 5% 20X40
R6811 0662057M61 RES. CHIP 300 5% 20X40
R6812 0662057M92 RES. CHIP 5600 5%
20X40
Reference
Designator
Motorola
Part Number
Description
R6813 0662057M74 RES. CHIP 1000 5%
20X40
R6814 0662057C55 CHIP RES 150 OHMS 5%
R6815 0662057M26 RES. CHIP 10 5% 20X40
R6816 0662057M61 RES. CHIP 300 5% 20X40
R6817 0662057M32 RES. CHIP 18 5% 20X40
R6818 0662057M61 RES. CHIP 300 5% 20X40
R6819 0662057N03 RES. CHIP 15K 5% 20X40
R6820 0662057M98 RES. CHIP 10K 5% 20X40
R6821 0662057A23 CHIP RES 82 OHMS 5%
R6823 0662057M63 RES CHIP 360 5% 20X40
R6824 0662057M61 RES. CHIP 300 5% 20X40
R6825 0662057M61 RES. CHIP 300 5% 20X40
R6826 0662057M32 RES. CHIP 18 5% 20X40
R6827 0662057M61 RES. CHIP 300 5% 20X40
R6828 0662057M54 RES. CHIP 150 5% 20X40
R6829 0662057M61 RES. CHIP 300 5% 20X40
R6830 0662057M61 RES. CHIP 300 5% 20X40
R6831 0662057M32 RES. CHIP 18 5% 20X40
R6833 0662057A23 CHIP RES 82 OHMS 5%
SH6000 NOTPLACED 64AM DUMMY PART
NUMBER
SH6730 NOTPLACED 64AM DUMMY PART
NUMBER
U0001 5185633C34 MODULE RAM/MEMORY
U0102 5185623B01 HIGH SPEED CMOS
INVERTER
U0103 5113837A15 IC 3.3V QUAD BUFFER
U0104 5113837A15 IC 3.3V QUAD BUFFER
U0105 5109522E17 IC SNGL NAND TC7S00FU
U0200 5105109Z38 3 VOLT LINEAR PCM
CODEC FILTER
U0201 5113819A14 IC QD OP AMP _33204_
U0202 5185353D35 IC DUAL EEPOT 256 TAP
U0203 5162852A79 IC MOS TTL SPDT
ANALOG SC70
U0204 5185794L01 AUDIO AMP TAPE AND
REEL
U0206 5185143E67 IC LM1971-62 DB LOG
POT
U0207 5109731C15 IC OP AMP SNGL OPA237
SOT23
U0208 5162852A79 IC MOS TTL SPDT
ANALOG SC70
U0209 5162852A79 IC MOS TTL SPDT
ANALOG SC70
U0210 5162852A79 IC MOS TTL SPDT
ANALOG SC70
U0300 5113837A15 IC 3.3V QUAD BUFFER
U0303 5113837A15 IC 3.3V QUAD BUFFER
U0304 5187970L15 IC USB TRANS FULL-
SPEED
Reference
Designator
Motorola
Part Number
Description
U0305 5185353D94 IC RS232 TRANSCEIVER
U0307 5109522E17 IC SNGL NAND TC7S00FU
U0308 5109522E74 IC 2-INPUT AND GATE
U0400 4880048M01 TSTR NPN DIG 47K/47K
U0401 5162852A79 IC MOS TTL SPDT
ANALOG SC70
U0402 5109522E53 IC SNGL BUF
NC7S125P5X SC70
U0500 5183308X01 IC, LM2941, TO DRPOUT
RGTR
U0501 5185353D55 IC VOLTAGE REGULATOR
100MZ ADJ
U0502 5185353D55 IC VOLTAGE REGULATOR
100MZ ADJ
U0503 5113816A07 REG 5V POS 500MA
MC78M05BDTRK
U0504 5185353D46 IF 4.3V VOLTAGE
DETECTOR
U0505 5113816A07 REG 5V POS 500MA
MC78M05BDTRK
U0506 5185143E57 CMOS TIMER-LMC555CM
U0507 5185353D55 IC VOLTAGE REGULATOR
100MZ ADJ
U0508 5109522E53 IC SNGL BUF
NC7S125P5X SC70
U0601 5109522E17 IC SNGL NAND TC7S00FU
U0602 5113837A15 IC 3.3V QUAD BUFFER
U0603 5113837A15 IC 3.3V QUAD BUFFER
U0604 5113818A14 IC DL OP AMP RAIL TO
RAIL
U0605 5109522E17 IC SNGL NAND TC7S00FU
U0606 5105109Z31 IC QUAD 2:1 MUX/DEMUX
U0607 5109522E74 IC 2-INPUT AND GATE
U0608 5109522E74 IC 2-INPUT AND GATE
U0609 5109522E17 IC SNGL NAND TC7S00FU
U0610 5109522E17 IC SNGL NAND TC7S00FU
U0900 5185368C83 IC 12 BIT DAC
U0901 5185143E43 IC 23 MACROCELL CPLD
U0902 5113805B39 IC MUX/DEMUX, TRIP 2-
CH ANALOG
U0903 5185143E68 IC LM7219 HIGH SPEED
COMPARATOR
U0950 5105625U25 IC 9.3V REG 2941
U0951 5105625U25 IC 9.3V REG 2941
U0952 5185353D35 IC DUAL EEPOT 256 TAP
U0953 5185143E16 IC ANALOG TO DIGITAL
CONVERTER
U0954 5109522E17 IC SNGL NAND TC7S00FU
U0955 5113819A14 IC QD OP AMP _33204_
U0956 5185956E24 QUAD OP AMP RAIL TO
RAIL 14
U0957 5113819A14 IC QD OP AMP _33204_
Reference
Designator
Motorola
Part Number
Description
U0958 5109522E17 IC SNGL NAND TC7S00FU
U0959 5185143E05 IC DAC OCTAL 8 BIT
U0960 5113819A14 IC QD OP AMP _33204_
U0962 5185353D14 IC SOT23-5 HI PRECISION
REG 3V
U0963 5109522E53 IC SNGL BUF
NC7S125P5X SC70
U6000 5185963A85 IC-ABACUS III-LP
U6002 5185353D14 IC SOT23-5 HI PRECISION
REG 3V
U6250 5186377E03 MMIC LNA 700-1000 MHZ
U6251 5185353D39 IC DOUBLE BALANCED
MIXER 700/800MHZ
U6252 5185963A87 IC ATTENUATOR
U6500 5185130C65 IC VHF/UHF/800 MHZ
LDMOS DRIVER
U6540 5185963A15 IC TEMPERTURE
SENSOR 1M50C
U6541 5185353D92 IC CURRENT SHUNT
MONITOR
U6750 5185353D14 IC SOT23-5 HI PRECISION
REG 3V
U6751 5185963A27 IC TESTED AT25016 48
PIN GFP
U6752 5105492X03 IC SNG HI SPD L-MOS
NOT GATE
U6754 0180706G62 MILLENNIUM TRANSMIT
VCO 700/800 MHZ
U6755 0180706G61 MILLENNIUM RECEIVER
VCO 700/800 MHZ
VR0400 4805656W09 DIODE QUAD 20 VOLT
ZENER
VR0402 4805656W09 DIODE QUAD 20 VOLT
ZENER
VR0404 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR0405 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR0406 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR0407 4805656W10 DIODE DUAL 15 VOLT
ZENER
VR0408 4813832C75 DIODE ZENER QU O
VR0410 4813832C75 DIODE ZENER QU O
VR0411 4805656W39 QUAD ESD
SUPPRESSOR ARRAY -
41206ESD
VR0412 4805656W09 DIODE QUAD 20 VOLT
ZENER
VR0413 NOTPLACED 64AM DUMMY PART
NUMBER
VR0414 4813832C75 DIODE ZENER QU O
VR0417 4813832C75 DIODE ZENER QU O
Reference
Designator
Motorola
Part Number
Description
