7-186 Schematics, Component Location Diagrams, and Parts Lists: HUF4017A (700-800 MHz) Main Board
June 15, 2005 6815854H01-A
R0901 0662057M96 RES. CHIP 8200 5%
20X40
R0902 0662057N23 RES. CHIP 100K 5%
20X40
R0903 0662057N23 RES. CHIP 100K 5%
20X40
R0904 0662057N23 RES. CHIP 100K 5%
20X40
R0905 0662057N23 RES. CHIP 100K 5%
20X40
R0907 0662057C01 CHIP RES 0 OHMS +.050
OHMS
R0930 0662057N06 RES. CHIP 20K 5% 20X40
R0931 0662057M98 RES. CHIP 10K 5% 20X40
R0936 0662057M98 RES. CHIP 10K 5% 20X40
R0937 0662057N10 RES. CHIP 30K 5% 20X40
R0938 0662057M98 RES. CHIP 10K 5% 20X40
R0939 0662057N10 RES. CHIP 30K 5% 20X40
R0940 0662057M01 RES. CHIP 0 5% 20X40
R0941 NOTPLACED 64AM DUMMY PART
NUMBER
R0942 0662057M96 RES. CHIP 8200 5%
20X40
R0943 0662057N06 RES. CHIP 20K 5% 20X40
R0944 0662057M98 RES. CHIP 10K 5% 20X40
R0945 0662057N11 RES. CHIP 33K 5% 20X40
R0946 NOTPLACED 64AM DUMMY PART
NUMBER
R0947 0662057M01 RES. CHIP 0 5% 20X40
R0948 NOTPLACED 64AM DUMMY PART
NUMBER
R0950 0662057M01 RES. CHIP 0 5% 20X40
R0951 0662057U98 RES CHIP 7.5K 1% 1/16W
R0952 0662057U78 RES CHIP 1.2K 1% 1/16W
R0953 0662057M01 RES. CHIP 0 5% 20X40
R0954 0662057U98 RES CHIP 7.5K 1% 1/16W
R0955 0662057N23 RES. CHIP 100K 5%
20X40
R0960 0662057N06 RES. CHIP 20K 5% 20X40
R0961 0662057N23 RES. CHIP 100K 5%
20X40
R0962 0662057N23 RES. CHIP 100K 5%
20X40
R0963 0662057N08 RES CHIP 24K 5% 20X40
R0964 0662057N08 RES CHIP 24K 5% 20X40
R0965 0662057M01 RES. CHIP 0 5% 20X40
R0966 0662057M01 RES. CHIP 0 5% 20X40
R0967 0662057V27 RES CHIP 100K 1% 1/1 6W
R0968 0662057V02 RES CHIP 10K 1% 1/16W
R0969 NOTPLACED 64AM DUMMY PART
NUMBER
Reference
Designator
Motorola
Part Number
Description
R0970 NOTPLACED 64AM DUMMY PART
NUMBER
R0971 0662057V02 RES CHIP 10K 1% 1/16W
R0972 0662057V02 RES CHIP 10K 1% 1/16W
R0973 0662057N01 RES CHIP 12K 5% 20X40
R0974 0662057V02 RES CHIP 10K 1% 1/16W
R0975 0662057V02 RES CHIP 10K 1% 1/16W
R0976 0662057M74 RES. CHIP 1000 5%
20X40
R0977 0662057M50 RES. CHIP 100 5% 20X40
R0978 0662057M98 RES. CHIP 10K 5% 20X40
R0979 0662057M01 RES. CHIP 0 5% 20X40
R0980 NOTPLACED 64AM DUMMY PART
NUMBER
R0981 0662057M84 RES. CHIP 2700 5%
20X40
R0982 0662057N23 RES. CHIP 100K 5%
20X40
R0983 0662057M81 RES. CHIP 2000 5%
20X40
R0984 0662057M01 RES. CHIP 0 5% 20X40
R0985 0662057M01 RES. CHIP 0 5% 20X40
R0986 NOTPLACED 64AM DUMMY PART
NUMBER
R0987 0662057M01 RES. CHIP 0 5% 20X40
R0988 0662057M98 RES. CHIP 10K 5% 20X40
R0989 0662057N17 RES. CHIP 56K 5% 20X40
R0990 0662057M91 RES CHIP 5100 5% 20X40
R0991 0662057M98 RES. CHIP 10K 5% 20X40
R0992 0662057V27 RES CHIP 100K 1% 1/1 6W
R0993 0662057U78 RES CHIP 1.2K 1% 1/16W
R0994 0662057M88 RES. CHIP 3900 5%
20X40
R0995 0662057U78 RES CHIP 1.2K 1% 1/16W
R0996 0662057M98 RES. CHIP 10K 5% 20X40
R0997 0662057U78 RES CHIP 1.2K 1% 1/16W
R0998 0662057V02 RES CHIP 10K 1% 1/16W
R0999 0662057V02 RES CHIP 10K 1% 1/16W
R6000 0662057M43 RES. CHIP 51 5% 20X40
R6001 0662057N47 RES. CHIP 1.0 MEG 5%
20X40
R6002 0662057N23 RES. CHIP 100K 5%
20X40
R6003 0662057M98 RES. CHIP 10K 5% 20X40
R6004 0662057M62 RES. CHIP 330 5% 20X40
R6005 0662057M98 RES. CHIP 10K 5% 20X40
R6006 0662057M46 RES. CHIP 68 5% 20X40
R6007 0662057M64 RES. CHIP 390 5% 20X40
R6008 0662057M98 RES. CHIP 10K 5% 20X40
R6009 0662057N08 RES CHIP 24K 5% 20X40
R6011 0662057M01 RES. CHIP 0 5% 20X40
R6012 0662057M01 RES. CHIP 0 5% 20X40
Reference
Designator
Motorola
Part Number
Description
R6013 0662057M01 RES. CHIP 0 5% 20X40
R6014 0662057M01 RES. CHIP 0 5% 20X40
R6015 0662057M01 RES. CHIP 0 5% 20X40
R6016 0662057M01 RES. CHIP 0 5% 20X40
R6019 0662057M74 RES. CHIP 1000 5%
20X40
R6020 0662057M98 RES. CHIP 10K 5% 20X40
R6021 0662057M98 RES. CHIP 10K 5% 20X40
R6022 0662057M01 RES. CHIP 0 5% 20X40
R6250 0662057N07 RES. CHIP 22K 5% 20X40
R6251 0662057M74 RES. CHIP 1000 5%
20X40
R6252 0662057N07 RES. CHIP 22K 5% 20X40
R6253 0662057A49 CHIP RES 1000 OHMS 5%
R6254 0662057M57 RES CHIP 200 5% 20X40
R6255 0662057M74 RES. CHIP 1000 5%
20X40
R6256 0662057M57 RES CHIP 200 5% 20X40
R6257 0662057N07 RES. CHIP 22K 5% 20X40
R6258 0662057M74 RES. CHIP 1000 5%
20X40
R6259 0662057M57 RES CHIP 200 5% 20X40
R6267 0662057A49 CHIP RES 1000 OHMS 5%
R6268 0662057M57 RES CHIP 200 5% 20X40
R6269 0662057M57 RES CHIP 200 5% 20X40
R6270 0662057M74 RES. CHIP 1000 5%
20X40
R6271 0662057M74 RES. CHIP 1000 5%
20X40
R6272 0662057M57 RES CHIP 200 5% 20X40
R6273 0662057M57 RES CHIP 200 5% 20X40
R6275 0662057A49 CHIP RES 1000 OHMS 5%
R6276 0662057A49 CHIP RES 1000 OHMS 5%
R6277 0662057M57 RES CHIP 200 5% 20X40
R6278 0662057M78 RES. CHIP 1500 5%
20X40
R6279 NOTPLACED 64AM DUMMY PART
NUMBER
R6280 0662057M78 RES. CHIP 1500 5%
20X40
R6281 0662057M19 RES. CHIP 5.1 5% 20X40
R6282 0662057M98 RES. CHIP 10K 5% 20X40
R6350 0662057M98 RES. CHIP 10K 5% 20X40
R6352 0662057N13 RES. CHIP 39K 5% 20X40
R6353 0662057M74 RES. CHIP 1000 5%
20X40
R6354 0662057A47 CHIP RES 820 OHMS 5%
R6520 0662057C75 CHIP RES 1000 OHMS 5%
R6521 0662057M24 RES CHIP 8.2 5% 20X40
R6522 0662057M24 RES CHIP 8.2 5% 20X40
R6523 0662057M24 RES CHIP 8.2 5% 20X40
R6524 0662057M24 RES CHIP 8.2 5% 20X40
Reference
Designator
Motorola
Part Number
Description
R6525 0662057M24 RES CHIP 8.2 5% 20X40
R6526 0680195M01 RES CHIP 10 OHMS 5%
.5W
R6527 0611077A01 RES CHIP JUMPER
R6540 0662057C75 CHIP RES 1000 OHMS 5%
R6543 0662057C75 CHIP RES 1000 OHMS 5%
R6544 0680195M01 RES CHIP 10 OHMS 5%
.5W
R6545 0685934D01 RES FIXED CHIP
(CURRENT SENOR)
R6546 0662057V27 RES CHIP 100K 1% 1/1 6W
R6547 0680194M13 RES 33 OHMS 5% 1W
R6548 0680194M13 RES 33 OHMS 5% 1W
R6549 0662057C27 CHIP RES 10 OHMS 5%
R6550 0662057B55 CHIP RES 2.0 OHMS 5%
R6551 0662057B55 CHIP RES 2.0 OHMS 5%
R6552 0662057B55 CHIP RES 2.0 OHMS 5%
R6553 0662057B55 CHIP RES 2.0 OHMS 5%
R6554 0662057B55 CHIP RES 2.0 OHMS 5%
R6555 0662057B55 CHIP RES 2.0 OHMS 5%
R6556 0662057B55 CHIP RES 2.0 OHMS 5%
R6557 0662057B55 CHIP RES 2.0 OHMS 5%
R6559 0611077A38 RES CHIP 33 5 1/8W
R6560 0611077A38 RES CHIP 33 5 1/8W
R6730 0680149M02 THERMISTOR CHIP 100K
OHM
R6731 0662057M98 RES. CHIP 10K 5% 20X40
R6732 0662057M78 RES. CHIP 1500 5%
20X40
R6733 0662057M55 RES CHIP 160 OHM 5%
R6734 0662057M55 RES CHIP 160 OHM 5%
R6735 0662057M56 RES. CHIP 180 5% 20X40
R6736 0662057M56 RES. CHIP 180 5% 20X40
R6737 0662057M78 RES. CHIP 1500 5%
20X40
R6738 0662057M98 RES. CHIP 10K 5% 20X40
R6739 0680149M02 THERMISTOR CHIP 100K
OHM
R6740 0611077A98 RES CHIP 10K 5 1/8W
R6752 0662057N23 RES. CHIP 100K 5%
20X40
R6753 0662057N23 RES. CHIP 100K 5%
20X40
R6754 0662057M74 RES. CHIP 1000 5%
20X40
R6755 0662057N23 RES. CHIP 100K 5%
20X40
R6756 0662057M74 RES. CHIP 1000 5%
20X40
R6757 0662057M50 RES. CHIP 100 5% 20X40
R6758 0662057M98 RES. CHIP 10K 5% 20X40
R6760 0662057M86 RES CHIP 3300 5% 20X40
Reference
Designator
Motorola
Part Number
Description
