Motorola Astro XTL 1500 - Page 424

Schematics, Component Location Diagrams, and Parts Lists: HUF4017A (700-800 MHz) Main Board 7-185
6815854H01-A June 15, 2005
Q6253 4813824A10 TSTR NPN 40V .2A GEN
PURP
Q6254 4813824A10 TSTR NPN 40V .2A GEN
PURP
Q6255 4880048M01 TSTR NPN DIG 47K/47K
Q6350 4805218N55 TRANSISTOR 3 LEAD
BFQ67
Q6520 4813828A09 TSTR 8W 450MHZ 7.5V
Q6540 4813828C46 TSTR 1 GHZ 45W TO270
T&R
Q6541 4813828C46 TSTR 1 GHZ 45W TO270
T&R
Q6753 4805921T04 XISTOR FMC1 RH
REELED
Q6755 4805921T04 XISTOR FMC1 RH
REELED
Q6756 4805921T04 XISTOR FMC1 RH
REELED
Q6757 4813824A10 TSTR NPN 40V .2A GEN
PURP
Q6758 4813824A10 TSTR NPN 40V .2A GEN
PURP
Q6759 4813824A17 XSTR PNP40V .2A GENP
B=100-300
Q6760 4805921T04 XISTOR FMC1 RH
REELED
Q6761 4809527E41 TRANSISTOR UHF
PRF949 SC75
Q6762 4809527E41 TRANSISTOR UHF
PRF949 SC75
Q6763 5186258W01 IC GAAS RF GAIN STAGE
Q6764 4809527E41 TRANSISTOR UHF
PRF949 SC75
Q6765 4809527E41 TRANSISTOR UHF
PRF949 SC75
Q6766 4809527E41 TRANSISTOR UHF
PRF949 SC75
R0101 NOTPLACED 64AM DUMMY PART
NUMBER
R0102 NOTPLACED 64AM DUMMY PART
NUMBER
R0103 NOTPLACED 64AM DUMMY PART
NUMBER
R0104 0662057M98 RES. CHIP 10K 5% 20X40
R0105 0662057M98 RES. CHIP 10K 5% 20X40
R0106 0662057M98 RES. CHIP 10K 5% 20X40
R0107 0662057M01 RES. CHIP 0 5% 20X40
R0108 NOTPLACED 64AM DUMMY PART
NUMBER
R0109 0662057M98 RES. CHIP 10K 5% 20X40
R0110 0662057M98 RES. CHIP 10K 5% 20X40
R0111 NOTPLACED 64AM DUMMY PART
NUMBER
Reference
Designator
Motorola
Part Number
Description
R0113 NOTPLACED 64AM DUMMY PART
NUMBER
R0114 0662057M01 RES. CHIP 0 5% 20X40
R0115 NOTPLACED 64AM DUMMY PART
NUMBER
R0116 0662057B46 CHIP RES 10.0 MEG
OHMS 5%
R0117 0662057B46 CHIP RES 10.0 MEG
OHMS 5%
R0119 0662057N39 RES. CHIP 470K 5%
20X40
R0120 0662057M98 RES. CHIP 10K 5% 20X40
R0121 0662057M98 RES. CHIP 10K 5% 20X40
R0122 0662057M86 RES CHIP 3300 5% 20X40
R0123 0662057M86 RES CHIP 3300 5% 20X40
R0124 NOTPLACED 64AM DUMMY PART
NUMBER
R0125 0662057M98 RES. CHIP 10K 5% 20X40
R0200 0662057M74 RES. CHIP 1000 5%
20X40
R0202 0662057M86 RES CHIP 3300 5% 20X40
R0203 0662057M74 RES. CHIP 1000 5%
20X40
R0204 0662057M68 RES CHIP 560 5% 20X40
R0205 0662057N15 RES. CHIP 47K 5% 20X40
R0206 NOTPLACED 64AM DUMMY PART
NUMBER
R0207 0662057M95 RES. CHIP 7500 5%
20X40
R0208 0662057N23 RES. CHIP 100K 5%
20X40
R0209 0662057M98 RES. CHIP 10K 5% 20X40
R0210 0662057N23 RES. CHIP 100K 5%
20X40
R0212 0662057N23 RES. CHIP 100K 5%
20X40
R0216 0662057N23 RES. CHIP 100K 5%
20X40
R0218 0662057M74 RES. CHIP 1000 5%
20X40
R0219 0662057M74 RES. CHIP 1000 5%
20X40
R0220 0662057N05 RES. CHIP 18K 5% 20X40
R0221 0662057M98 RES. CHIP 10K 5% 20X40
R0222 0662057M98 RES. CHIP 10K 5% 20X40
R0223 0662057N05 RES. CHIP 18K 5% 20X40
R0224 0662057M98 RES. CHIP 10K 5% 20X40
R0225 0662057M98 RES. CHIP 10K 5% 20X40
R0226 0662057N12 RES. CHIP 36K 5% 20X40
R0227 0662057N19 RES. CHIP 68K 5% 20X40
R0228 0662057N11 RES. CHIP 33K 5% 20X40
R0229 0662057N19 RES. CHIP 68K 5% 20X40
Reference
Designator
Motorola
Part Number
Description
R0230 0662057N11 RES. CHIP 33K 5% 20X40
R0231 0662057C01 CHIP RES 0 OHMS +.050
OHMS
R0235 0662057M98 RES. CHIP 10K 5% 20X40
R0236 0662057M97 RES CHIP 9100 5% 20X40
R0303 0662057M78 RES. CHIP 1500 5%
20X40
R0304 0662057M34 RES. CHIP 22 5% 20X40
R0305 0662057M34 RES. CHIP 22 5% 20X40
R0307 0662057M98 RES. CHIP 10K 5% 20X40
R0403 0662057M98 RES. CHIP 10K 5% 20X40
R0404 0662057M74 RES. CHIP 1000 5%
20X40
R0405 0662057M74 RES. CHIP 1000 5%
20X40
R0406 0662057M68 RES CHIP 560 5% 20X40
R0407 0662057M50 RES. CHIP 100 5% 20X40
R0408 0662057M50 RES. CHIP 100 5% 20X40
R0409 0662057M98 RES. CHIP 10K 5% 20X40
R0410 0662057M50 RES. CHIP 100 5% 20X40
R0411 0662057M98 RES. CHIP 10K 5% 20X40
R0412 0662057M50 RES. CHIP 100 5% 20X40
R0415 0662057M50 RES. CHIP 100 5% 20X40
R0416 0662057M50 RES. CHIP 100 5% 20X40
R0417 0662057M50 RES. CHIP 100 5% 20X40
R0418 0662057M50 RES. CHIP 100 5% 20X40
R0419 0662057M90 RES. CHIP 4700 5%
20X40
R0420 0662057M98 RES. CHIP 10K 5% 20X40
R0421 0662057M01 RES. CHIP 0 5% 20X40
R0422 0662057V15 RES CHIP 33K 1% 1/16W
R0425 0662057M98 RES. CHIP 10K 5% 20X40
R0430 0662057M01 RES. CHIP 0 5% 20X40
R0431 0662057M98 RES. CHIP 10K 5% 20X40
R0432 0662057M50 RES. CHIP 100 5% 20X40
R0435 0662057M74 RES. CHIP 1000 5%
20X40
R0500 0662057N23 RES. CHIP 100K 5%
20X40
R0502 0662057N37 RES CHIP 390K 5% 20X40
R0503 0662057N23 RES. CHIP 100K 5%
20X40
R0504 0662057N23 RES. CHIP 100K 5%
20X40
R0505 0662057M98 RES. CHIP 10K 5% 20X40
R0506 0662057M98 RES. CHIP 10K 5% 20X40
R0507 0662057M98 RES. CHIP 10K 5% 20X40
R0508 0662057M98 RES. CHIP 10K 5% 20X40
R0509 0662057M81 RES. CHIP 2000 5%
20X40
R0510 0662057V18 RES CHIP 43K 1% 1/16W
R0511 0662057V15 RES CHIP 33K 1% 1/16W
Reference
Designator
Motorola
Part Number
Description
R0512 0662057V02 RES CHIP 10K 1% 1/16W
R0513 0662057V17 RES CHIP 39K 1% 1/16W
R0514 0662057M01 RES. CHIP 0 5% 20X40
R0515 0662057M74 RES. CHIP 1000 5%
20X40
R0516 0662057N23 RES. CHIP 100K 5%
20X40
R0517 0662057M90 RES. CHIP 4700 5%
20X40
R0518 0662057M98 RES. CHIP 10K 5% 20X40
R0519 0662057C27 CHIP RES 10 OHMS 5%
R0520 0662057N15 RES. CHIP 47K 5% 20X40
R0521 0662057V17 RES CHIP 39K 1% 1/16W
R0522 0662057V10 RES CHIP 20K 1% 1/16W
R0523 0662057N23 RES. CHIP 100K 5%
20X40
R0524 NOTPLACED 64AM DUMMY PART
NUMBER
R0527 NOTPLACED 64AM DUMMY PART
NUMBER
R0528 0662057M95 RES. CHIP 7500 5%
20X40
R0529 0662057M76 RES. CHIP 1200 5% 20X40
R0531 0662057N23 RES. CHIP 100K 5%
20X40
R0620 0662057M50 RES. CHIP 100 5% 20X40
R0621 0662057M50 RES. CHIP 100 5% 20X40
R0622 0662057M50 RES. CHIP 100 5% 20X40
R0623 0662057M50 RES. CHIP 100 5% 20X40
R0625 0662057M98 RES. CHIP 10K 5% 20X40
R0626 0662057N23 RES. CHIP 100K 5%
20X40
R0627 0662057N23 RES. CHIP 100K 5%
20X40
R0628 0662057N23 RES. CHIP 100K 5%
20X40
R0629 0662057M98 RES. CHIP 10K 5% 20X40
R0630 0662057N23 RES. CHIP 100K 5%
20X40
R0631 0662057M01 RES. CHIP 0 5% 20X40
R0632 NOTPLACED 64AM DUMMY PART
NUMBER
R0634 0662057N23 RES. CHIP 100K 5%
20X40
R0635 0662057N23 RES. CHIP 100K 5%
20X40
R0636 0662057M98 RES. CHIP 10K 5% 20X40
R0638 0662057M98 RES. CHIP 10K 5% 20X40
R0639 0662057M98 RES. CHIP 10K 5% 20X40
R0900 NOTPLACED 64AM DUMMY PART
NUMBER
Reference
Designator
Motorola
Part Number
Description
