7-184 Schematics, Component Location Diagrams, and Parts Lists: HUF4017A (700-800 MHz) Main Board
June 15, 2005 6815854H01-A
C6833 2113743L41 CAP CHIP 10000 PF 10%
X7R
C6834 2113743N40 CAP CHIP 39.0 PF 5%
COG
C6835 2113743N40 CAP CHIP 39.0 PF 5%
COG
C6836 2113743N13 CAP CHIP 3.0 PF +-.25PF
COG
C6837 2113743S01 CAP CER CHIP 1.0 UF
10% 16V
C6838 2113743L41 CAP CHIP 10000 PF 10%
X7R
C6839 2113743L41 CAP CHIP 10000 PF 10%
X7R
C6840 2113743N40 CAP CHIP 39.0 PF 5%
COG
C6841 2113743N40 CAP CHIP 39.0 PF 5%
COG
D0501 4805218N57 DIODE DUAL
D0950 4813833C02 DIODE DUAL 70V '5B'
COMM CATH
D0951 4813833C02 DIODE DUAL 70V '5B'
COMM CATH
D0952 4813833C02 DIODE DUAL 70V '5B'
COMM CATH
D6030 4805656W28 DIODE VARACTOR
18PF@1V +6PF@4V
D6051 4809877C13 DIODE VARACTOR
ISV305 SMD
D6250 4880154K06 DIODE PIN SCHOTTKY
D6251 4880154K06 DIODE PIN SCHOTTKY
D6252 4880154K06 DIODE PIN SCHOTTKY
D6253 4880154K06 DIODE PIN SCHOTTKY
D6254 4880154K06 DIODE PIN SCHOTTKY
D6255 4880154K06 DIODE PIN SCHOTTKY
D6256 4880154K06 DIODE PIN SCHOTTKY
D6257 4880154K06 DIODE PIN SCHOTTKY
D6258 4880154K03 DIODE DUAL SCHOTTKY
MIXER
D6701 4802482J02 PIN DIODE SMD
D6702 4802482J02 PIN DIODE SMD
D6730 4805218N57 DIODE DUAL
D6731 4805218N57 DIODE DUAL
D6750 4813833C02 DIODE DUAL 70V '5B'
COMM CATH
D6751 4802233J09 DIODE TRIPLE SOT25-RH
D6752 4802233J09 DIODE TRIPLE SOT25-RH
E6000 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E6001 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E6002 2480640Z01 SURFACE MOUNT
FERRITE BEAD
Reference
Designator
Motorola
Part Number
Description
E6003 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E6004 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E6005 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E6006 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E6007 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E6008 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E6751 NOTPLACED 64AM DUMMY PART
NUMBER
E6752 NOTPLACED 64AM DUMMY PART
NUMBER
E6753 NOTPLACED 64AM DUMMY PART
NUMBER
F0400 6583049X16 FUSE 5A FAST ACT
FL0900 9185130D01 FLTR SW CAP 3 POLE
BUTTERW
J0401 0985722E01 CONN 50 POS FM SMT
RTANG
J0402 0985631E01 CONNECTOR FEMALE 32
PIN ACCY
J0501 0985473E01 CONN SECURE 20 POS
FM SMT RT ANG
J0950 0905902V07 CONNECTOR DC
J6700 0905901V11 CONNECTOR RF
L6000 2462587N57 CHIP IND 220 NH 5%
L6001 2405769X05 COIL INDUCTOR
L6002 2405769X05 COIL INDUCTOR
L6003 2462587N76 CHIP IND 4700 NH 5%
L6004 2404574Z34 INDUCTOR 270 NH 2%
0805 WIREWOUND
L6005 2462587N73 WIREWOUND INDUCTOR
2700 NH 5% 1008
L6012 2462587L50 FERRITE INDUCTOR
100UH
L6250 2462587T38 IND CHIP 22NH 5% LOW
PRO
L6251 2462587T38 IND CHIP 22NH 5% LOW
PRO
L6252 2462587N51 CHIP IND 68 NH 5%
L6253 2462587T38 IND CHIP 22NH 5% LOW
PRO
L6254 2462587T38 IND CHIP 22NH 5% LOW
PRO
L6255 2462587T30 IND CHIP 1000NH 5%
LOW PRO
L6256 2462587T30 IND CHIP 1000NH 5%
LOW PRO
Reference
Designator
Motorola
Part Number
Description
L6257 2462587T30 IND CHIP 1000NH 5%
LOW PRO
L6258 2488428L05 IND CHIP WW 7.5NH 5%
2.1A 1608
L6259 2462587T30 IND CHIP 1000NH 5%
LOW PRO
L6260 2462587T38 IND CHIP 22NH 5% LOW
PRO
L6261 2462587T38 IND CHIP 22NH 5% LOW
PRO
L6262 2462587T38 IND CHIP 22NH 5% LOW
PRO
L6263 2462587T38 IND CHIP 22NH 5% LOW
PRO
L6350 2462587N65 CHIP IND 750 NH 5%
L6351 2462587N64 CHIP IND 680 NH 5%
L6352 2462587N69 CHIP IND 1200 NH 5%
L6353 2462587N65 CHIP IND 750 NH 5%
L6355 2462587N68 CHIP IND 1000 NH 5%
L6500 2462587T17 IND CHIP 150NH 5% LOW
PRO
L6501 2462587T17 IND CHIP 150NH 5% LOW
PRO
L6502 2488428L05 IND CHIP WW 7.5NH 5%
2.1A 1608
L6521 2484562T04 COIL SURFACE MOUNT
AIR WOUND
L6522 2484657R01 INDUCTOR BEAD CHIP
L6542 2460592A01 COIL AW 2 TURN 17 NH
L6543 2484657R01 INDUCTOR BEAD CHIP
L6700 2462587T17 IND CHIP 150NH 5% LOW
PRO
L6702 2462587T17 IND CHIP 150NH 5% LOW
PRO
L6703 2462587V60 IND CHIP 43 NH 5%
L6720 2484562T21 COIL AIR WOUND ENCAP
SPRING AUTO INSERT
L6721 2484562T21 COIL AIR WOUND ENCAP
SPRING AUTO INSERT
L6722 2484562T21 COIL AIR WOUND ENCAP
SPRING AUTO INSERT
L6730 2488428L09 IND CHIP WW 18 NH 5%
1.9A 1608
L6731 2488428L06 COILCRAFT 0603HC
L6750 2462587Q20 IND CHIP 2,200 NH 20%
L6751 2462587Q20 IND CHIP 2,200 NH 20%
L6752 2462587Q20 IND CHIP 2,200 NH 20%
L6753 2462587Q20 IND CHIP 2,200 NH 20%
L6754 2462587T30 IND CHIP 1000NH 5%
LOW PRO
L6755 2462587Q44 IND CHIP 560 NH 10%
L6756 2462587Q47 IND CHIP 1,000 NH 10%
L6757 2462587V20 CHIP IND 3.3 NH 5% 0805
Reference
Designator
Motorola
Part Number
Description
L6758 2462587V23 CHIP IND 12 NH 5% 0805
L6760 2462587V22 CHIP IND 8.2 NH 5% 0805
L6761 2462587Q44 IND CHIP 560 NH 10%
L6763 2462587V22 CHIP IND 8.2 NH 5% 0805
M6520 2685838C01 HEATSINK PLD1.5
TRANSISTOR ASSY
M6542 2685837C03 HEATSINK TRANSISTOR
CARRIER
M6700 NOTPLACED 64AM DUMMY PART
NUMBER
M6720 2685059F01 SHIELD,FLTR,,,,,,,SHIELD
HAR FLTR
M6721 NOTPLACED 64AM DUMMY PART
NUMBER
PCB 8485429D01 MAIN BOARD
Q0200 4880048M01 TSTR NPN DIG 47K/47K
Q0402 4880048M01 TSTR NPN DIG 47K/47K
Q0403 4805723X03 TRANS DUAL NPN-PNP
UMD3N ROHM
Q0404 4880048M01 TSTR NPN DIG 47K/47K
Q0500 4880048M01 TSTR NPN DIG 47K/47K
Q0501 4880048M01 TSTR NPN DIG 47K/47K
Q0502 4880048M01 TSTR NPN DIG 47K/47K
Q0503 4813821A09 TSTR P-CH 60V 12A
_2955_
Q0504 4880048M01 TSTR NPN DIG 47K/47K
Q0505 4880048M01 TSTR NPN DIG 47K/47K
Q0610 4805723X03 TRANS DUAL NPN-PNP
UMD3N ROHM
Q0611 4805723X03 TRANS DUAL NPN-PNP
UMD3N ROHM
Q0612 4805723X03 TRANS DUAL NPN-PNP
UMD3N ROHM
Q0613 4805723X03 TRANS DUAL NPN-PNP
UMD3N ROHM
Q0951 4880048M01 TSTR NPN DIG 47K/47K
Q0952 4885844C01 XSTR FET
Q0953 NOTPLACED 64AM DUMMY PART
NUMBER
Q0954 4809579E16 TSTR MOSFET N-CHAN
TN0200T
Q0955 4809579E16 TSTR MOSFET N-CHAN
TN0200T
Q6000 4805218N63 RF TRANS SOT 323
BFQ67W
Q6001 4805128M19 TSTR SOT23 MMBTA13
RH
Q6250 4813824A10 TSTR NPN 40V .2A GEN
PURP
Q6251 4805921T04 XISTOR FMC1 RH
REELED
Q6252 4805921T04 XISTOR FMC1 RH
REELED
Reference
Designator
Motorola
Part Number
Description
