Schematics, Component Location Diagrams, and Parts Lists: HUF4017A (700-800 MHz) Main Board 7-183

6815854H01-A June 15, 2005

C6501 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6502 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6503 2113743N50 CAP CHIP 100 PF 5% COG

C6504 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6506 2113743N30 CAP CHIP 15.0 PF 5%

COG

C6507 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6508 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6509 2113743N28 CAP CHIP 12.0 PF 5%

COG

C6510 2113743N28 CAP CHIP 12.0 PF 5%

COG

C6511 2113743N20 CAP CHIP 5.6 PF + -.5PF

COG

C6520 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6521 2111078B32 CAP CHIP RF 39 5 NPO

100V

C6522 2113741N69 CAP CHIP CL2 X7R 10%

100000

C6523 2113741N69 CAP CHIP CL2 X7R 10%

100000

C6524 2113741N69 CAP CHIP CL2 X7R 10%

100000

C6525 NOTPLACED 64AM DUMMY PART

NUMBER

C6540 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6541 2111078B14 CAP CHIP RF 11 5 NPO

100V

C6542 2111078B15 CAP CHIP RF 12 5 NPO

100V

C6544 2111078B15 CAP CHIP RF 12 5 NPO

100V

C6545 2111078B15 CAP CHIP RF 12 5 NPO

100V

C6547 2111078B15 CAP CHIP RF 12 5 NPO

100V

C6548 2111078B14 CAP CHIP RF 11 5 NPO

100V

C6549 2111078B16 CAP CHIP RF 13 5 NPO

100V

C6550 2111078B15 CAP CHIP RF 12 5 NPO

100V

C6551 2111078B06 CAP CHIP RF 5.1 .25 NPO

100V

C6552 2111078B15 CAP CHIP RF 12 5 NPO

100V

Reference

Designator

Motorola

Part Number

Description

C6553 2111078B06 CAP CHIP RF 5.1 .25 NPO

100V

C6554 2111078B16 CAP CHIP RF 13 5 NPO

100V

C6555 2111078B13 CAP CHIP RF 10 .5 NPO

100V

C6556 2111078B01 CAP CHIP RF 3.3 .25 NPO

100V

C6557 2111078B32 CAP CHIP RF 39 5 NPO

100V

C6558 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6559 2111078B32 CAP CHIP RF 39 5 NPO

100V

C6560 2113741N69 CAP CHIP CL2 X7R 10%

100000

C6561 2113743E20 CAP CHIP .10 UF 10%

C6562 2113743E20 CAP CHIP .10 UF 10%

C6563 2311049A78 CAP TANT CHIP 10.0 UF

10% 50V

C6564 NOTPLACED 64AM DUMMY PART

NUMBER

C6565 2113740B39 CAP CHIP REEL CL1 +/-30

C6566 2113740B39 CAP CHIP REEL CL1 +/-30

C6700 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6701 2111078B32 CAP CHIP RF 39 5 NPO

100V

C6703 2111078B20 CAP CHIP RF 18 5 NPO

100V

C6704 2111078B32 CAP CHIP RF 39 5 NPO

100V

C6705 2111078B32 CAP CHIP RF 39 5 NPO

100V

C6720 2111078B05 CAP CHIP RF 4.7 .25 NPO

100V

C6721 2111078B05 CAP CHIP RF 4.7 .25 NPO

100V

C6730 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6731 2113743N19 CAP CHIP 5.1 PF + -.5PF

COG

C6732 2113743N19 CAP CHIP 5.1 PF + -.5PF

COG

C6733 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6734 2113951A07 CAP NPO 0.70PF +/-.1PF

250V HI FREQ

C6735 2113951A07 CAP NPO 0.70PF +/-.1PF

250V HI FREQ

C6750 2113743E20 CAP CHIP .10 UF 10%

Reference

Designator

Motorola

Part Number

Description

C6751 2113743S01 CAP CER CHIP 1.0 UF

10% 16V

C6753 2113743E20 CAP CHIP .10 UF 10%

C6755 2113743N50 CAP CHIP 100 PF 5% COG

C6757 2113743E20 CAP CHIP .10 UF 10%

C6758 2113743L17 CAP CHIP 1000 PF 10%

X7R

C6759 2113743N38 CAP CHIP 33.0 PF 5%

COG

C6760 2113743L17 CAP CHIP 1000 PF 10%

X7R

C6761 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6763 2113743E20 CAP CHIP .10 UF 10%

C6764 2113743E20 CAP CHIP .10 UF 10%

C6765 2113743E20 CAP CHIP .10 UF 10%

C6766 2113743E20 CAP CHIP .10 UF 10%

C6767 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6768 2113743T19 CAP 10UF 16V CER 3225

X5R

C6769 2113743E20 CAP CHIP .10 UF 10%

C6771 2113743E20 CAP CHIP .10 UF 10%

C6773 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6775 2113743T19 CAP 10UF 16V CER 3225

X5R

C6776 2113743E12 CAP CHIP .047 UF 10%

X7R

C6777 2113743E07 CER CHIP CAP .022UF

C6778 2113743E12 CAP CHIP .047 UF 10%

X7R

C6779 2113743E07 CER CHIP CAP .022UF

C6780 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6781 NOTPLACED 64AM DUMMY PART

NUMBER

C6782 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6783 2185419D08 CAP CER SUPER L/D

0.0012UF

C6784 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6785 2185419D06 CAP CER SUPER L/D

0.1UF

C6786 2185419D06 CAP CER SUPER L/D

0.1UF

C6787 2185419D06 CAP CER SUPER L/D

0.1UF

C6788 2185419D06 CAP CER SUPER L/D

0.1UF

C6789 2185419D06 CAP CER SUPER L/D

0.1UF

Reference

Designator

Motorola

Part Number

Description

C6790 2113743K15 CER CHIP CAP .100UF

C6791 2113743K15 CER CHIP CAP .100UF

C6792 2113743T19 CAP 10UF 16V CER 3225

X5R

C6794 2113743A27 CAP CHIP .470 UF 10%

16V

C6795 2113743A27 CAP CHIP .470 UF 10%

16V

C6797 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6798 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6801 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6802 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6806 2113743E07 CER CHIP CAP .022UF

C6807 2113743K15 CER CHIP CAP .100UF

C6808 2113743T19 CAP 10UF 16V CER 3225

X5R

C6813 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6817 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6818 2113743T19 CAP 10UF 16V CER 3225

X5R

C6819 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6820 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6821 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6822 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6823 2113743E20 CAP CHIP .10 UF 10%

C6824 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6825 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6826 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6827 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6828 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6829 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6830 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6831 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6832 2113743N40 CAP CHIP 39.0 PF 5%

COG

Reference

Designator

Motorola

Part Number

Description
