7-182 Schematics, Component Location Diagrams, and Parts Lists: HUF4017A (700-800 MHz) Main Board

June 15, 2005 6815854H01-A

C0981 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0982 2311049C47 CAP TANT CHIP 22.0UF

10% 16V

C0983 2113743N50 CAP CHIP 100 PF 5% COG

C0984 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0985 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0986 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C0987 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C6000 2113743N37 CAP CHIP 30.0 PF 5%

COG

C6001 2113743N36 CAP CHIP 27.0 PF 5%

COG

C6002 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6003 2113740F58 CAP CHIP REEL CL1 +/-30

200

C6005 2113743N50 CAP CHIP 100 PF 5% COG

C6006 2113743N50 CAP CHIP 100 PF 5% COG

C6007 2113743L25 CAP CHIP 2200 PF 10%

X7R

C6010 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6011 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6012 2113743N50 CAP CHIP 100 PF 5% COG

C6013 2113743N50 CAP CHIP 100 PF 5% COG

C6015 NOTPLACED 64AM DUMMY PART

NUMBER

C6016 2113928N01 CAP CER CHIP 0.1UF 10%

6.3

C6017 2113928N01 CAP CER CHIP 0.1UF 10%

6.3

C6018 2113928N01 CAP CER CHIP 0.1UF 10%

6.3

C6019 2113928N01 CAP CER CHIP 0.1UF 10%

6.3

C6020 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6021 2113743L17 CAP CHIP 1000 PF 10%

X7R

C6022 2113928N01 CAP CER CHIP 0.1UF 10%

6.3

C6023 2113928N01 CAP CER CHIP 0.1UF 10%

6.3

C6024 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6025 2113928N01 CAP CER CHIP 0.1UF 10%

6.3

Reference

Designator

Motorola

Part Number

Description

C6026 2113743N36 CAP CHIP 27.0 PF 5%

COG

C6030 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6031 2113743N46 QAP CHIP 68.0 PF 5%

COG

C6032 2113928N01 CAP CER CHIP 0.1UF 10%

6.3

C6033 2113743B27 CAP CHIP .680 UF 10%

X7R

C6051 2113743N46 QAP CHIP 68.0 PF 5%

COG

C6052 2113743N43 CAP CHIP 51.0 PF 5%

COG

C6053 2113743N25 CAP CHIP 9.1 PF + -.5PF

COG

C6054 2113743N28 CAP CHIP 12.0 PF 5%

COG

C6055 2113743N24 CAP CHIP 8.2 PF + -.5PF

COG

C6056 2113743E20 CAP CHIP .10 UF 10%

C6057 2113743A27 CAP CHIP .470 UF 10%

16V

C6058 NOTPLACED 64AM DUMMY PART

NUMBER

C6059 2113928N01 CAP CER CHIP 0.1UF 10%

6.3

C6060 2113928N01 CAP CER CHIP 0.1UF 10%

6.3

C6061 NOTPLACED 64AM DUMMY PART

NUMBER

C6064 2113928N01 CAP CER CHIP 0.1UF 10%

6.3

C6067 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6068 2113743S01 CAP CER CHIP 1.0 UF

10% 16V

C6084 2113743A31 CAP CHIP 1.0 UF 10% X7R

C6091 2113743F18 CAP CHIP 2.2 UF 16V +80-

20%

C6096 2113928N01 CAP CER CHIP 0.1UF 10%

6.3

C6250 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6251 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6252 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6253 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6254 2113743L41 CAP CHIP 10000 PF 10%

X7R

Reference

Designator

Motorola

Part Number

Description

C6255 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6256 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6257 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6258 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6259 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6260 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6261 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6262 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6263 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6264 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C6265 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6266 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6267 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6268 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6269 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6270 2113743N42 CAP CHIP 47.0 PF 5%

COG

C6271 2113743N26 CAP CHIP 10.0 PF 5%

COG

C6272 2113743N42 CAP CHIP 47.0 PF 5%

COG

C6273 2113743N42 CAP CHIP 47.0 PF 5%

COG

C6274 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6275 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6276 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6277 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6278 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6279 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6280 2113743L41 CAP CHIP 10000 PF 10%

X7R

Reference

Designator

Motorola

Part Number

Description

C6281 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6282 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6283 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6284 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6285 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6286 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6287 2113743L41 CAP CHIP 10000 PF 10%

X7R

C6288 2113743N16 CAP CHIP 3.9 PF +-.25PF

COG

C6289 2113743M24 CAP CHIP 100000 PF +80-

20% Y5V

C6293 2113743N40 CAP CHIP 39.0 PF 5%

COG

C6295 2113743L17 CAP CHIP 1000 PF 10%

X7R

C6296 2113743N42 CAP CHIP 47.0 PF 5%

COG

C6297 2113743N25 CAP CHIP 9.1 PF + -.5PF

COG

C6298 2113743L09 CAP CHIP 470 PF 10%

X7R

C6299 2113743L17 CAP CHIP 1000 PF 10%

X7R

C6350 NOTPLACED 64AM DUMMY PART

NUMBER

C6351 2113743N58 CAP CHIP 4.0PF 16V

.25PF COG

C6352 2113743N20 CAP CHIP 5.6 PF + -.5PF

COG

C6353 2113743N26 CAP CHIP 10.0 PF 5%

COG

C6354 2113928N01 CAP CER CHIP 0.1UF 10%

6.3

C6355 2113743Q03 CAP CHIP 1.0 PF +/-.1PF

20*40

C6356 2113743N58 CAP CHIP 4.0PF 16V

.25PF COG

C6357 NOTPLACED 64AM DUMMY PART

NUMBER

C6358 2113928N01 CAP CER CHIP 0.1UF 10%

6.3

C6359 2113928N01 CAP CER CHIP 0.1UF 10%

6.3

C6500 2113743L41 CAP CHIP 10000 PF 10%

X7R

Reference

Designator

Motorola

Part Number

Description
