June 15, 2005 6815854H01-A
4-4 Troubleshooting Procedures: Power-Up Self-Check Errors
FAIL 01/88 External RAM Error FATAL • Turn the radio off, then on.
• Hard bootstrap and flash the
firmware.
• Replace the daughtercard.
FAIL 01/90 General Hardware FATAL • Turn the radio off, then on.
• Replace the control head or flex.
FAIL 01/92 Security Partition
Checksum
FATAL Re-flash the codeplug sections.
FAIL 01/93 FlashPORT AUTHENT
CODE Failure
FATAL Re-flash the appropriate base
codeplug to match the radio
feature set.
FAIL 01/98 Internal RAM Failure FATAL • Turn the radio off, then on.
• Hard bootstrap and flash the
firmware.
• Replace the daughtercard.
FAIL 01/AO ABACUS IC Failure/Wrong
ABACUS IC Version
FATAL • Re-flash tuning (codeplug).
• Retune the radio using CPS.
FAIL 01/A2 Tuning Codeplug
Checksum
FATAL • Re-flash tuning (codeplug).
• Retune the radio using CPS.
FAIL 02/81 DSP ROM Checksum FATAL • Turn the radio off, then on.
• Re-flash the DSP firmware
(DSP is processor-dependent).
FAIL 02/88 DSP RAM Error FATAL • Turn the radio off, then on.
• Re-flash the DSP firmware
(DSP is processor-dependent).
FAIL 02/90 General DSP Hardware
Failure
FATAL • Turn the radio off, then on.
• Re-flash the DSP firmware
(DSP is processor-dependent).
• Replace daughtercard.
FAIL 02/CO Wrong Microprocessor
Version
FATAL • Re-flash the firmware.
• Hard bootstrap and flash the
firmware.
• Replace the daughtercard.
ERROR 05/10 Control Head Hardware
Error
NON-FATAL • Turn the radio off, then on.
• Replace the control head or flex.
FAIL 05/81 Control Head ROM
Checksum Error
FATAL Replace the control head.
ERROR 06/10 Aux Control Head
Hardware Error
NON-FATAL • Turn the radio off, then on.
• Replace the control head or flex.
FAIL 06/81 Aux Control Head ROM
Checksum Error
FATAL Replace the auxiliary control
head.
ERROR 08/10 Siren Hardware Error NON-FATAL • Turn the radio off, then on.
• Check the siren cable
connection.
FAIL 08/81 Siren ROM Checksum
Error
FATAL Replace the siren.
ERROR 09/10 Secure Hardware Error NON-FATAL Replace the secure module.
Table 4-1. Power-Up Self-Check Error Codes (Continued)
Error Code Description Error Type Corrective Action
