Motorola Astro XTL 1500 - Page 340

Schematics, Component Location Diagrams, and Parts Lists: HUE4039A (UHF Range 1) Main Board 7-101
6815854H01-A June 15, 2005
L5283 2462587V33 CHIP IND 82 NH 5% 0805
L5284 2462587V25 CHIP IND 18 NH 5% 0805
L5285 2413926N22 IND CER CHIP 68.0 NH 5%
L5286 2413926N20 IND CER CHIP 47.0 NH 5%
L5287 2413926N16 IND CER CHIP 22.0 NH 5%
L5288 2462587V33 CHIP IND 82 NH 5% 0805
L5289 2462587V59 IND CHIP 390 NH 5%
L5290 2462587T30 IND CHIP 1000NH 5% LOW
PRO
L5291 2462587T30 IND CHIP 1000NH 5% LOW
PRO
L5292 2462587V59 IND CHIP 390 NH 5%
L5293 2462587V59 IND CHIP 390 NH 5%
L5294 2462587V29 CHIP IND 39 NH 5% 0805
L5295 2462587V59 IND CHIP 390 NH 5%
L5296 2462587T30 IND CHIP 1000NH 5% LOW
PRO
L5297 2462587V27 CHIP IND 27 NH 5% 0805
L5298 2462587V26 CHIP IND 22 NH 5% 0805
L5299 2484657R01 INDUCTOR BEAD CHIP
L5300 2462587V27 CHIP IND 27 NH 5% 0805
L5301 2462587V27 CHIP IND 27 NH 5% 0805
L5302 2462587V23 CHIP IND 12 NH 5% 0805
L5303 2462587V32 CHIP IND 68 NH 5% 0805
L5304 2462587V27 CHIP IND 27 NH 5% 0805
L5305 2462587V24 CHIP IND 15 NH 5% 0805
L5306 2462587V22 CHIP IND 8.2 NH 5% 0805
L5307 2462587V22 CHIP IND 8.2 NH 5% 0805
L5308 2462587V24 CHIP IND 15 NH 5% 0805
L5380 2462587V21 CHIP IND 6.8 NH 5% 0805
L5381 2462587V22 CHIP IND 8.2 NH 5% 0805
L5384 2462587V21 CHIP IND 6.8 NH 5% 0805
L5385 2413926N12 IND CER CHIP 10.0 MH 5%
L5386 2413926N12 IND CER CHIP 10.0 MH 5%
L5387 2413926N12 IND CER CHIP 10.0 MH 5%
L5388 2462587V32 CHIP IND 68 NH 5% 0805
L5389 2413926N12 IND CER CHIP 10.0 MH 5%
L5390 2462587V32 CHIP IND 68 NH 5% 0805
L5392 2462587V23 CHIP IND 12 NH 5% 0805
L5400 2462587V59 IND CHIP 390 NH 5%
L5401 2462587V59 IND CHIP 390 NH 5%
Reference
Designator
Motorola
Part Number
Description
L5402 2462587V59 IND CHIP 390 NH 5%
L5403 2462587V59 IND CHIP 390 NH 5%
L5404 2462587V52 IND CHIP 270NH 5%
L5406 2462587V38 CHIP IND 220 NH 5% 0805
L5407 2462587V38 CHIP IND 220 NH 5% 0805
L5408 2462587N68 CHIP IND 1000 NH
L5411 2462587V38 CHIP IND 220 NH 5% 0805
L5501 2462587V25 CHIP IND 18 NH 5% 0805
L5502 2462587V59 IND CHIP 390 NH 5%
L5503 2462587V23 CHIP IND 12 NH 5% 0805
L5504 2462587V38 CHIP IND 220 NH 5% 0805
L5505 2462587V59 IND CHIP 390 NH 5%
L5506 2462587V26 CHIP IND 22 NH 5% 0805
L5507 2462587V26 CHIP IND 22 NH 5% 0805
L5508 2484562T04 COIL SURFACE MOUNT AIR
WOUND
L5510 2460592A01 COIL AW 2 TURN 17 NH
L5701 2462587N61 CHIP IND 470 NH
L5702 2462587N55 CHIP IND 150 NH
L5703 2460592A01 COIL AW 2 TURN 17 NH
L5704 2460592A01 COIL AW 2 TURN 17 NH
L5705 2462587N61 CHIP IND 470 NH
L5706 2460592A01 COIL AW 2 TURN 17 NH
L5707 2460592A01 COIL AW 2 TURN 17 NH
L5708 2460592A01 COIL AW 2 TURN 17 NH
L5712 2484562T02 COIL SURFACE MOUNT AIR
WOUND
L5713 2484562T02 COIL SURFACE MOUNT AIR
WOUND
L5750 2462587Q44 IND CHIP 560 NH 10%
L5751 2462587Q44 IND CHIP 560 NH 10%
L5752 2462587Q20 IND CHIP 2,200 NH 20%
L5753 2462587N68 CHIP IND 1000 NH
L5754 2462587Q20 IND CHIP 2,200 NH 20%
L5755 2462587Q20 IND CHIP 2,200 NH 20%
L5756 2462587Q20 IND CHIP 2,200 NH 20%
L5757 2413926H14 IND CHIP 15.0 NH 5%
L5758 2462587T30 IND CHIP 1000NH 5% LOW
PRO
L5759 2413926H14 IND CHIP 15.0 NH 5%
L5760 2462587P25 CHIP IND 12000 NH 5%
L5825 2462587V24 CHIP IND 15 NH 5% 0805
Reference
Designator
Motorola
Part Number
Description
L5826 2462587V59 IND CHIP 390 NH 5%
L5827 2462587V59 IND CHIP 390 NH 5%
L5828 2462587V24 CHIP IND 15 NH 5% 0805
L5829 2413926N29 IND CER CHIP 270.0 NH 5%
L5830 2413926N29 IND CER CHIP 270.0 NH 5%
L5831 2413926N27 COIL 30X60 INDUCTOR 180.0
NH
L5832 2413926N29 IND CER CHIP 270.0 NH 5%
L5833 2413926N28 IND CER CHIP 220.0MH 5%
L5834 2413926N27 COIL 30X60 INDUCTOR 180.0
NH
L5900 2413926N26 COIL 30X60 INDUCTOR 150.0
NH
L5901 2462587V40 IND CHIP 330 NH 10%
L5902 2462587T37 IND CHIP 18NH 5% LOW PRO
L5904 2462587V40 IND CHIP 330 NH 10%
L5905 2462587V40 IND CHIP 330 NH 10%
L5906 2413926N26 COIL 30X60 INDUCTOR 150.0
NH
L5907 2413926N26 COIL 30X60 INDUCTOR 150.0
NH
L5908 2462587V40 IND CHIP 330 NH 10%
L5909 2462587T37 IND CHIP 18NH 5% LOW PRO
L5910 2462587V40 IND CHIP 330 NH 10%
L5911 2462587T37 IND CHIP 18NH 5% LOW PRO
L5912 2462587V40 IND CHIP 330 NH 10%
L5913 2462587V40 IND CHIP 330 NH 10%
L5914 2462587V40 IND CHIP 330 NH 10%
L5915 2462587V40 IND CHIP 330 NH 10%
L5916 2413926N26 COIL 30X60 INDUCTOR 150.0
NH
L5917 2413926N13 ND CER CHIP 12.0 NH 5%
L5918 2413926N15 IND CER CHIP 18.0 NH 5%
L5919 2413926N13 ND CER CHIP 12.0 NH 5%
L5922 2413926N28 IND CER CHIP 220.0MH 5%
M5501 2685838C01 HEATSINK PLD1.5
TRANSISTOR ASSY
M5502 2685837C04 HEATSINK TRANSISTOR
CARRIER
PCB 8485314E01 PCB MILLENNIUM UHF
Q0200 4880048M01 TSTR NPN DIG 47K/47K
Q0402 4880048M01 TSTR NPN DIG 47K/47K
Reference
Designator
Motorola
Part Number
Description
Q0403 4805723X03 TRANS DUAL NPN-PNP
UMD3N ROHM
Q0404 4880048M01 TSTR NPN DIG 47K/47K
Q0500 4880048M01 TSTR NPN DIG 47K/47K
Q0501 4880048M01 TSTR NPN DIG 47K/47K
Q0502 4880048M01 TSTR NPN DIG 47K/47K
Q0503 4813821A09 TSTR P-CH 60V 12A _2955_
Q0504 4880048M01 TSTR NPN DIG 47K/47K
Q0505 4880048M01 TSTR NPN DIG 47K/47K
Q0610 4805723X03 TRANS DUAL NPN-PNP
UMD3N ROHM
Q0611 4805723X03 TRANS DUAL NPN-PNP
UMD3N ROHM
Q0612 4805723X03 TRANS DUAL NPN-PNP
UMD3N ROHM
Q0613 4805723X03 TRANS DUAL NPN-PNP
UMD3N ROHM
Q0951 4880048M01 TSTR NPN DIG 47K/47K
Q0952 4885844C01 XSTR FET
Q0954 4809579E16 TSTR MOSFET N-CHAN
TN0200T
Q0955 4809579E16 TSTR MOSFET N-CHAN
TN0200T
Q0960 4805723X03 TRANS DUAL NPN-PNP
UMD3N ROHM
Q5001 4813824A10 TSTR NPN 40V .2A GEN
PURP
Q5002 4805218N63 RF TRANS SOT 323 BFQ67W
Q5003 4805218N63 RF TRANS SOT 323 BFQ67W
Q5250 4813824A10 TSTR NPN 40V .2A GEN
PURP
Q5251 4813824A10 TSTR NPN 40V .2A GEN
PURP
Q5252 4805218N63 RF TRANS SOT 323 BFQ67W
Q5253 4813824A17 XSTR PNP40V .2A GENP
B=100-300
Q5254 4813824A10 TSTR NPN 40V .2A GEN
PURP
Q5255 4813824A10 TSTR NPN 40V .2A GEN
PURP
Q5256 4813824A17 XSTR PNP40V .2A GENP
B=100-300
Q5257 4880048M01 TSTR NPN DIG 47K/47K
Q5258 4813824A17 XSTR PNP40V .2A GENP
B=100-300
Reference
Designator
Motorola
Part Number
Description
