7-104 Schematics, Component Location Diagrams, and Parts Lists: HUE4039A (UHF Range 1) Main Board
June 15, 2005 6815854H01-A
R5530 0662057C20 CHIP RES 5.1 OHMS 5%
R5532 0662057C13 CHIP RES 2.7 OHMS 5%
R5533 0662057C20 CHIP RES 5.1 OHMS 5%
R5534 0662057C20 CHIP RES 5.1 OHMS 5%
R5535 0680195M01 RES CHIP 10 OHMS 5% .5W
R5536 0662057C20 CHIP RES 5.1 OHMS 5%
R5570 0662057C13 CHIP RES 2.7 OHMS 5%
R5571 0662057N11 RES. CHIP 33K 5% 20X40
R5572 0662057U98 RES CHIP 7.5K 1% 1/16W
R5573 0662057U78 RES CHIP 1.2K 1% 1/16W
R5574 0611077A01 RES CHIP JUMPER
R5701 0680194M13 RES 33 OHMS 5% 1W
R5702 0662057A53 CHIP RES 1500 OHMS 5%
R5703 0662057A84 CHIP RES 30K OHMS 5%
R5704 0680149M02 THERMISTOR CHIP 100K
OHM
R5705 0662057A35 CHIP RES 270 OHMS 5%
R5706 0662057A35 CHIP RES 270 OHMS 5%
R5707 0662057A35 CHIP RES 270 OHMS 5%
R5708 0662057A35 CHIP RES 270 OHMS 5%
R5709 0662057A53 CHIP RES 1500 OHMS 5%
R5710 0662057A94 CHIP RES 75K OHMS 5%
R5711 0662057A84 CHIP RES 30K OHMS 5%
R5712 0680149M02 THERMISTOR CHIP 100K
OHM
R5750 0662057M74 RES. CHIP 1000 5% 20X40
R5751 0662057M98 RES. CHIP 10K 5% 20X40
R5752 0662057N15 RES. CHIP 47K 5% 20X40
R5753 0662057M91 RES CHIP 5100 5% 20X40
R5754 0662057N15 RES. CHIP 47K 5% 20X40
R5755 0662057M01 RES. CHIP 0
R5758 0662057M86 RES CHIP 3300 5% 20X40
R5759 0662057M81 RES. CHIP 2000 5% 20X40
R5761 0662057N23 RES. CHIP 100K 5% 20X40
R5762 0662057N23 RES. CHIP 100K 5% 20X40
R5763 0662057M74 RES. CHIP 1000 5% 20X40
R5764 0662057N15 RES. CHIP 47K 5% 20X40
R5765 0662057M91 RES CHIP 5100 5% 20X40
R5766 0662057N23 RES. CHIP 100K 5% 20X40
R5767 0662057N15 RES. CHIP 47K 5% 20X40
R5768 0662057M50 RES. CHIP 100 5% 20X40
Reference
Designator
Motorola
Part Number
Description
R5769 0662057M01 RES. CHIP 0
R5771 0662057M54 RES. CHIP 150 5% 20X40
R5772 0662057M71 RES CHIP 750 5% 20X40
R5773 0662057M54 RES. CHIP 150 5% 20X40
R5774 0662057M48 RES. CHIP 82 5% 20X40
R5775 0662057M50 RES. CHIP 100 5% 20X40
R5776 0662057M74 RES. CHIP 1000 5% 20X40
R5777 0662057M74 RES. CHIP 1000 5% 20X40
R5778 0662057M72 RES. CHIP 820 5% 20X40
R5779 0662057N01 RES CHIP 12K 5% 20X40
R5780 0662057M84 RES. CHIP 2700 5% 20X40
R5782 0662057N15 RES. CHIP 47K 5% 20X40
R5783 0662057N15 RES. CHIP 47K 5% 20X40
R5784 0662057N15 RES. CHIP 47K 5% 20X40
R5785 0662057N15 RES. CHIP 47K 5% 20X40
R5786 0662057N15 RES. CHIP 47K 5% 20X40
R5825 0662057M83 RES. CHIP 2400 5% 20X40
R5826 0662057M88 RES. CHIP 3900 5% 20X40
R5827 0662057M60 RES. CHIP 270 5% 20X40
R5828 0662057M66 RES. CHIP 470 5% 20X40
R5829 0662057M74 RES. CHIP 1000 5% 20X40
R5830 0662057M77 RES. CHIP 1300 5% 20X40
R5831 0662057M38 RES. CHIP 33 5% 20X40
R5832 0662057M38 RES. CHIP 33 5% 20X40
R5833 0662057M60 RES. CHIP 270 5% 20X40
R5834 0662057M60 RES. CHIP 270 5% 20X40
R5837 0662057M50 RES. CHIP 100 5% 20X40
R5838 0662057M50 RES. CHIP 100 5% 20X40
R5839 0662057M43 RES. CHIP 51 5% 20X40
R5840 0662057M43 RES. CHIP 51 5% 20X40
R5841 0662057M50 RES. CHIP 100 5% 20X40
R5842 0662057M50 RES. CHIP 100 5% 20X40
R5843 0662057M58 RES. CHIP 220 5% 20X40
R5845 0662057M84 RES. CHIP 2700 5% 20X40
R5846 0662057N01 RES CHIP 12K 5% 20X40
R5848 0662057M72 RES. CHIP 820 5% 20X40
R5849 0662057M30 RES. CHIP 15 5% 20X40
R5850 0662057M58 RES. CHIP 220 5% 20X40
R5851 0662057M90 RES. CHIP 4700 5% 20X40
R5852 0662057M90 RES. CHIP 4700 5% 20X40
R5853 0662057M74 RES. CHIP 1000 5% 20X40
Reference
Designator
Motorola
Part Number
Description
R5854 0662057M63 RES CHIP 360 5% 20X40
R5855 0662057M01 RES. CHIP 0
R5900 0662057M81 RES. CHIP 2000 5% 20X40
R5902 0662057M58 RES. CHIP 220 5% 20X40
R5903 0662057M81 RES. CHIP 2000 5% 20X40
R5904 0662057M60 RES. CHIP 270 5% 20X40
R5905 0662057M50 RES. CHIP 100 5% 20X40
R5909 0662057M30 RES. CHIP 15 5% 20X40
R5910 0662057M38 RES. CHIP 33 5% 20X40
R5911 0662057M66 RES. CHIP 470 5% 20X40
R5912 0662057M81 RES. CHIP 2000 5% 20X40
R5914 0662057M72 RES. CHIP 820 5% 20X40
R5915 0662057M60 RES. CHIP 270 5% 20X40
R5916 0662057M79 RES CHIP 1600 5% 20X40
R5917 0662057N01 RES CHIP 12K 5% 20X40
R5918 0662057M50 RES. CHIP 100 5% 20X40
R5919 0662057M47 RES CHIP 75 5% 20X40
R5921 0662057M84 RES. CHIP 2700 5% 20X40
R5922 0662057M38 RES. CHIP 33 5% 20X40
R5923 0662057M66 RES. CHIP 470 5% 20X40
R5924 0662057M79 RES CHIP 1600 5% 20X40
R5926 0662057M72 RES. CHIP 820 5% 20X40
R5927 0662057M81 RES. CHIP 2000 5% 20X40
R5928 0662057M60 RES. CHIP 270 5% 20X40
R5929 0662057N01 RES CHIP 12K 5% 20X40
R5930 0662057M43 RES. CHIP 51 5% 20X40
R5931 0662057M47 RES CHIP 75 5% 20X40
R5932 0662057M47 RES CHIP 75 5% 20X40
R5933 0662057M84 RES. CHIP 2700 5% 20X40
R5934 0662057M38 RES. CHIP 33 5% 20X40
R5935 0662057M66 RES. CHIP 470 5% 20X40
R5937 0662057M62 RES. CHIP 330 5% 20X40
R5938 0662057M90 RES. CHIP 4700 5% 20X40
R5939 0662057M90 RES. CHIP 4700 5% 20X40
R5940 0662057M63 RES CHIP 360 5% 20X40
R5948 0662057M47 RES CHIP 75 5% 20X40
R5949 0662057M30 RES. CHIP 15 5% 20X40
R5950 0662057M58 RES. CHIP 220 5% 20X40
SH5400 2685882A01 SHLD VCO TANK
T5380 2584600T01 BALUN RF
T5381 2584600T01 BALUN RF
Reference
Designator
Motorola
Part Number
Description
U0001 5185633C34 MODULE RAM/MEMORY
U0102 5185623B01 HIGH SPEED CMOS
INVERTER
U0103 5113837A15 IC 3.3V QUAD BUFFER
U0104 5113837A15 IC 3.3V QUAD BUFFER
U0105 5109522E17 IC SNGL NAND TC7S00FU
U0200 5105109Z38 3 VOLT LINEAR PCM CODEC
FILTER
U0201 5113819A14 IC QD OP AMP _33204_
U0202 5185353D35 IC DUAL EEPOT 256 TAP
U0203 5162852A79 IC MOS TTL SPDT ANALOG
SC70
U0204 5185794L01 AUDIO AMP TAPE AND REEL
U0206 5185143E67 IC LM1971-62 DB LOG POT
U0208 5162852A79 IC MOS TTL SPDT ANALOG
SC70
U0209 5162852A79 IC MOS TTL SPDT ANALOG
SC70
U0210 5162852A79 IC MOS TTL SPDT ANALOG
SC70
U0300 5113837A15 IC 3.3V QUAD BUFFER
U0303 5113837A15 IC 3.3V QUAD BUFFER
U0304 5187970L15 IC USB TRANS FULL-SPEED
U0305 5185353D94 IC RS232 TRANSCEIVER
U0307 5113805B65 IC 2 INPUT NAND
U0308 5109522E74 IC 2-INPUT AND GATE
U0400 4880048M01 TSTR NPN DIG 47K/47K
U0401 5162852A79 IC MOS TTL SPDT ANALOG
SC70
U0402 5109522E53 IC SNGL BUF NC7S125P5X
SC70
U0500 5183308X01 IC, LM2941, TO DRPOUT
RGTR
U0501 5185353D55 IC VOLTAGE REGULATOR
100MZ ADJ
U0502 5185353D55 IC VOLTAGE REGULATOR
100MZ ADJ
U0503 5113816A07 REG 5V POS 500MA
MC78M05BDTRK
U0504 5185353D46 IF 4.3V VOLTAGE DETECTOR
U0505 5113816A07 REG 5V POS 500MA
MC78M05BDTRK
U0506 5185143E57 CMOS TIMER-LMC555CM
Reference
Designator
Motorola
Part Number
Description
