Scanner Emulation Interface 10 - 11
Check For Decode LED
The attached decoder normally asserts the Decode line to signal to the Scanner Emulation Host that it has
successfully decoded the transmitted bar code. Some decoders, however, do not assert the Decode signal to tell
the scanner that a decode has occurred. In this case, the scanner emits Transmit Error beeps to indicate that the
bar code was not successfully transmitted. Scanning the "Ignore Decode LED" bar code below to disable the
Transmit Error beeps.
*Check For Decode LED
Ignore Decode LED
