6 - 6 Symbol LS3408 Product Reference Guide

RS-232 Host Types

To select an RS-232 host type, scan one of the following bar codes.

*Standard RS-232

ICL RS-232

Wincor-Nixdorf RS-232 Mode A

Wincor-Nixdorf RS-232 Mode B

Olivetti ORS4500

Omron

OPOS/JPOS

Fujitsu RS-232
