12 - 44 Symbol LS3408 Product Reference Guide

GS1 DataBar (formerly Reduced Space Symbology)

GS1 DataBar

The variants of GS1 DataBar are GS1 DataBar-14, GS1 DataBar Expanded, and GS1 DataBar Limited. The limited

and expanded versions have stacked variants. Scan the appropriate bar code below to enable or disable each

variant of GS1 DataBar.

GS1 DataBar-14

Enable GS1 DataBar-14

*Disable GS1 DataBar-14

GS1 DataBar Limited

Enable GS1 DataBar Limited

*Disable GS1 DataBar Limited
