Motorola Symbol LS3408 - RS-232 Default Parameters

RS-232 Interface 6 - 3
RS-232 Default Parameters
Table 6-1 lists the defaults for RS-232 host parameters. To change any option, scan the appropriate bar code(s)
provided in the Parameter Descriptions section beginning on page 6-4.
NOTE See Appendix A, Standard Default Parameters for all user preferences, hosts, symbologies, and
miscellaneous default parameters.
Table 6-1 RS-232 Host Default Table
Parameter Default
Page
Number
RS-232 Host Parameters
RS-232 Host Types Standard RS-232 6-6
Baud Rate 9600 6-7
Parity None 6-8
Check Receive Errors Enable 6-9
Stop Bit Select 1 Stop Bit 6-10
Data Bits 8-Bit 6-10
Hardware Handshaking None 6-11
Software Handshaking None 6-13
Host Serial Response Time-out Minimum: 2 sec 6-15
RTS Line State Host: Low RTS 6-16
Beep on <BEL> Disable 6-16
Intercharacter Delay Minimum: 0 msec 6-17
Nixdorf Beep/LED Options Normal Operation 6-18
Ignore Unknown Characters Send Bar Code 6-18
