3 - 4 Symbol LS3408 Product Reference Guide
Technical Specifications
NOTE If after performing these checks the symbol still does not decode, contact the distributor or contact
Motorola Enterprise Mobility Support. See page xv for the telephone numbers.
Table 3-2 Technical Specifications
Item
Description
Symbol LS3408-FZ Symbol LS3408-ER
Power Requirements 4.5 - 14VDC
Stand-By Current 50mA (max)
Power Source Depending on host:
• host powered
• external power supply
Decode Capability UPC/EAN, Bookland EAN, UPC/EAN with supplementals, Code 128, UCC/EAN 128,
ISBT 128, Code 39, Trioptic Code 39, Code 93, Code 11, Interleaved 2 of 5, Discrete
2 of 5, Codabar (NW-7), MSI, GS1 DataBar.
Beeper Operation User-selectable: Enable, Disable
Beeper Volume User-selectable: Three levels
Beeper Tone User-selectable: Three tones
Scan Repetition Rate 36 scans/second
Yaw Tolerance ± 50° from nominal ± 60° from nominal
Pitch Tolerance ± 65° from nominal ± 65° from nominal
Roll Tolerance ± 20° from nominal ± 10° from nominal
Print Contrast Minimum 25% minimum reflectance differential, measured at 650 nm.
Ambient Light Immunity
Indoor:
Outdoor:
450 Ft Candles (4,842 Lux)
8,000 Ft Candles (86,080 Lux)
450 Ft Candles (4,842 Lux)
4,000 Ft Candles (43,040 Lux)
Durability 6.5 ft (2.0 m) drops to concrete
Operating Temperature -22° to 122° F (-30° to 50° C)
Storage Temperature -40° to 158° F (-40° to 70° C)
Humidity 5% to 95% (non-condensing)
Weight (without cable) 12.35 oz. (350 g) 12.56 oz. (356 g)
