Pin Description
2 Data -
3 Data +
4 Permits distinction of host connection from slave
5 Signal ground
Five-Slot Charge Only Cradle CRDUNIV-55-5000R Technical
Specifications
Table 11: Five-Slot Charge Only Cradle Technical Specifications
Item Description
Dimensions
Height: 90.1 mm (3.5 in.)
Width: 449.6 mm (17.7 in.)
Depth: 120.3 mm (4.7 in.)
Weight 1.31 kg (2.89 lbs.)
Input Voltage 12 VDC
Power Consumption 37.5 watts
Operating Temperature 0 °C to 50 °C (32 °F to 122 °F)
Storage Temperature -40 °C to 70 °C (-40 °F to 158 °F)
Charging Temperature 0 °C to 40 °C (32 °F to 104 °F)
Humidity 0% to 95% non-condensing
Drop 76.2 cm (30.0 in.) drops to vinyl tiled concrete at room temperature.
Electrostatic Discharge (ESD)
+/- 15 kV air
+/- 8 kV contact
134 | Technical Specifications
Send Feedback | October 2013 | MN000017A01
