Motorola TC55 Integrator Guide

Type Actions Description
Pad with spaces Left pad data with spaces to meet the specified length. Enter the number
spaces to pad.
Stop pad spaces Stop padding with spaces. This disables the previous Pad with spaces
action.
Replace string Replaces a specified string with a new string. Enter the string to replace
and the string to replace it with.
Stop all replace string Stop all Replace string actions.
Data Sending Send next Sends the specified number of characters from the current cursor
position. Enter the number of characters to send.
Send remaining Sends all data that remains from the current cursor position.
Send up to Sends all data up to a specified string. Enter the string.
Send pause Pauses the specified number of milliseconds before continuing the next
action. Enter the amount of time in milliseconds.
Send string Sends a specified string. Enter the string to send.
Send char Sends a specified ASCII/ Unicode character. Enter a character value.
The maximum Unicode character value can be entered is U-10FFFF (=
1114111 in decimal).
Deleting an Action
Procedure:
1 Touch and hold the action name.
2 Select Delete action from the context menu.
ADF Example
The following illustrates an example of creating Advanced Data Formatting:
When a user scans a bar code with the following criteria:
• Code 39 bar code.
• length of 12 characters.
• contains 129 at the start position.
Modify the data as follows:
• Pad all sends with zeros to length 8.
• send all data up to character X.
• send a space character.
To create an ADF rule for the above example:
Procedure:
1
Touch
.
2 Touch DataWedge.
3 Touch Profile0.
4 Under Keystroke Output, touch Advanced data formatting.
5 Touch Enable.
6 Touch Rule0.
DataWedge Configuration | 69
MN000017A01 | October 2013 | Send Feedback
