Install 2 adjusting screws (M6).
Mount gasket (Arrow).
(S) Adjusting screws M6 504189
Fasten complete valve block uniformly with socket head screws
(2 pieces M6 x 105 and 21 pieces M6 x 80 mm).
Pay attention to the position of the two socket head screws (M6
x 105), see Arrows !
Torque limit ........................................ 11 Nm
(S) Box spanner TX-27 504253
Figure 39
Figure 40
