TRANSMISSION
Ch 2 page 160 Ch 2 page 161
TRANSMISSION
TRANSMISSION
Ch 2 page 160 Ch 2 page 161
TRANSMISSION
Figure 155
Figure 156
Loosen screw connection and separate housing cover by means of
back-off screws (arrows) and lifting device from the gearbox hous-
ing.
During the separating procedure, drive out the output shaft by tap
-
ping continuously downwards!
(S) Back-off screws 504183
(S) Lifting device 504198
(S) Plastic hammer 504196
Loosen hex. head screws and remove cover plate.
Assembly,
see the section: Manual transmission assembly
