SHOP MANUAL MT26/31 - 12.2004SHOP MANUAL MT26/31 - 12.2004
DRIVE LINE
CH 3 PAGE 12
SHOP MANUAL MT26/31 - 12.2004SHOP MANUAL MT26/31 - 12.2004
Shims
Note:
It is no pre-tension in the pinion unit.
Clearance is maximum 0,1 mm (0,05 - 0,1 mm)
