6. COMMUNICATIONS MEMORY MAP
6-21
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
START 02B0 Overload Lockout Block 0 500 1 min F1 0
BLOCKS 02B1 Start Inhibit Block Lockout Time 1 500 1 min F1 1
02B2 Starts/Hour Block Lockout Time 1 60 1 min F1 1
02B3 Time Between Starts Lockout Time 1 500 1 min F1 1
02B4 Restart Block Lockout 1 30000 1 s F1 1
02B5 Reserved
... ...
02CF Reserved
DIGITAL 02D0 Access Switch Status 0 1 1 - FC131 0
INPUTS 02D1 Test Switch Status 0 1 1 - FC131 0
02D2 Starter Switch Status 0 1 1 - FC131 0
02D3 Emergency Restart Switch Status 0 1 1 - FC131 0
02D4 Remote Reset Switch Status 0 1 1 - FC131 0
02D5 Assignable Switch #1 Status 0 1 1 - FC131 0
02D6 Assignable Switch #2 Status 0 1 1 - FC131 0
02D7 Assignable Switch #3 Status 0 1 1 - FC131 0
02D8 Assignable Switch #4 Status 0 1 1 - FC131 0
02D9 Trip Coil Supervision 0 1 1 - FC132 0
02DA Reserved
... ...
02FB Reserved
REAL TIME 02FC Date (Read Only) N/A N/A N/A N/A F18 N/A
CLOCK 02FE Time (Read Only) N/A N/A N/A N/A F19 N/A
CURRENT 0300 Phase A Current 0 100000 1 A F9 0
METERING 0302 Phase B Current 0 100000 1 A F9 0
0304 Phase C Current 0 100000 1 A F9 0
0306 Average Phase Current 0 100000 1 A F9 0
0308 Motor Load 0 2000 1 FLA F3 0
0309 Current Unbalance 0 100 1 % F1 0
030A Equivalent Motor Load 0 2000 1 FLA F3 0
030B Ground Current 0 500000 1 A F11 0
030D Phase A Differential Current 0 5000 1 A F1 0
030E Phase B Differential Current 0 5000 1 A F1 0
030F Phase C Differential Current 0 5000 1 A F1 0
0310 Reserved
... ...
031F Reserved
TEMPERATU
RE
0320 Hottest Stator RTD -50 250 1
o
CF4 0
0321 RTD #1 Temperature -50 250 1
o
CF4 0
0322 RTD #2 Temperature -50 250 1
o
CF4 0
0323 RTD #3 Temperature -50 250 1
o
CF4 0
