Multilin SR469 - Page 170

6. COMMUNICATIONS MEMORY MAP
6-22
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
0324 RTD #4 Temperature -50 250 1
o
CF4 0
0325 RTD #5 Temperature -50 250 1
o
CF4 0
0326 RTD #6 Temperature -50 250 1
o
CF4 0
0327 RTD #7 Temperature -50 250 1
o
CF4 0
0328 RTD #8 Temperature -50 250 1
o
CF4 0
0329 RTD #9 Temperature -50 250 1
o
CF4 0
032A RTD #10 Temperature -50 250 1
o
CF4 0
032B RTD #11 Temperature -50 250 1
o
CF4 0
032C RTD #12 Temperature -50 250 1
o
CF4 0
032D Reserved
032E Reserved
032F Reserved
0330 Hottest Stator RTD (in Fahrenheit) -58 482 1
o
FF4 32
0331 RTD #1 Temperature (in Fahrenheit) -58 482 1
o
FF4 32
0332 RTD #2 Temperature (in Fahrenheit) -58 482 1
o
FF4 32
0333 RTD #3 Temperature (in Fahrenheit) -58 482 1
o
FF4 32
0334 RTD #4 Temperature (in Fahrenheit) -58 482 1
o
FF4 32
0335 RTD #5 Temperature (in Fahrenheit) -58 482 1
o
FF4 32
0336 RTD #6 Temperature (in Fahrenheit) -58 482 1
o
FF4 32
0337 RTD #7 Temperature (in Fahrenheit) -58 482 1
o
FF4 32
0338 RTD #8 Temperature (in Fahrenheit) -58 482 1
o
FF4 32
0339 RTD #9 Temperature (in Fahrenheit) -58 482 1
o
FF4 32
033A RTD #10 Temperature (in Fahrenheit) -58 482 1
o
FF4 32
033B RTD #11 Temperature (in Fahrenheit) -58 482 1
o
FF4 32
033C RTD #12 Temperature (in Fahrenheit) -58 482 1
o
FF4 32
033D Reserved
033E Reserved
033F Reserved
VOLTAGE 0340 Vab 0 20000 1 V F1 0
METERING 0341 Vbc 0 20000 1 V F1 0
0342 Vca 0 20000 1 V F1 0
0343 Average Line Voltage 0 20000 1 V F1 0
0344 Van 0 20000 1 V F1 0
0345 Vbn 0 20000 1 V F1 0
0346 Vcn 0 20000 1 V F1 0
0347 Average_Phase_Voltage 0 20000 1 V F1 0
0348 System Frequency 0 12000 1 Hz F3 0
0349 Reserved
... ...
035F Reserved
SPEED 0360 Tachometer RPM 0 3600 1 R.P.M. F1 0
0361 Reserved
