Multilin SR469 - Page 171

6. COMMUNICATIONS MEMORY MAP
6-23
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
... ...
036F Reserved
POWER 0370 Power Factor -99 100 1 - F21 0
METERING 0371 Real Power -50000 50000 1 kW F12 0
0373 Real Power (HP) 0 65000 1 hp F1 0
0374 Reactive Power -50000 50000 1 kvar F12 0
0376 Apparent Power 0 50000 1 kVA F1 0
0377 MWh Consumption 0 999999999 1 MWh F17 0
0379 Mvarh Consumption 0 999999999 1 Mvarh F17 0
037B Mvarh Generation 0 999999999 1 Mvarh F17 0
037D Torque 0 9999999 1 Nm/ftlb F2 0
037F Reserved
... ...
038F Reserved
DEMAND 0390 Current Demand 0 100000 1 A F9 0
METERING 0392 Real Power Demand -50000 50000 1 kW F12 0
0394 Reactive Power Demand -50000 50000 1 kvar F12 0
0396 Apparent Power Demand 0 50000 1 kVA F1 0
0397 Peak Current Demand 0 100000 1 A F9 0
0399 Peak Real Power Demand -50000 50000 1 kW F12 0
039B Peak Reactive Power Demand -50000 50000 1 kvar F12 0
039D Peak Apparent Power Demand 0 50000 1 kVA F1 0
039E Reserved
...
03AF Reserved
ANALOG 03B0 Analog I/P 1 -50000 50000 1 - F12 0
INPUTS 03B2 Analog I/P 2 -50000 50000 1 - F12 0
03B4 Analog I/P 3 -50000 50000 1 - F12 0
03B6 Analog I/P 4 -50000 50000 1 - F12 0
03B8 Analog Diff 1-2 Absolute -100000 100000 1 - F12 0
03BA Analog Diff 3-4 Absolute -100000 100000 1 - F12 0
03BC Reserved
... ...
03BF Reserved
MOTOR 03C0 Learned Acceleration Time 0 2000 1 s F2 0
STARTING 03C1 Learned Starting Current 0 50000 1 A F9 0
03C3 Learned Starting Capacity 0 100 1 % F1 0
03C4 Last Acceleration Time 0 2000 1 s F2 0
03C5 Last Starting Current 0 50000 1 A F9 0
03C7 Last Starting Capacity 0 100 1 % F1 0
03C8 Reserved
... ...
