Multilin SR469 - Page 172

6. COMMUNICATIONS MEMORY MAP
6-24
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
03CF Reserved
AVERAGE 03D0 Average Motor Load Learned 0 2000 1 x FLA F3 5
MOTOR 03D1 Reserved
LOAD ... ...
03DF Reserved
RTD 03E0 RTD # 1 Max. Temperature -50 250 1
o
CF4 0
MAXIMUMS 03E1 RTD # 2 Max. Temperature -50 250 1
o
CF4 0
03E2 RTD # 3 Max. Temperature -50 250 1
o
CF4 0
03E3 RTD # 4 Max. Temperature -50 250 1
o
CF4 0
03E4 RTD # 5 Max. Temperature -50 250 1
o
CF4 0
03E5 RTD # 6 Max. Temperature -50 250 1
o
CF4 0
03E6 RTD # 7 Max. Temperature -50 250 1
o
CF4 0
03E7 RTD # 8 Max. Temperature -50 250 1
o
CF4 0
03E8 RTD # 9 Max. Temperature -50 250 1
o
CF4 0
03E9 RTD # 10 Max. Temperature -50 250 1
o
CF4 0
03EA RTD # 11 Max. Temperature -50 250 1
o
CF4 0
03EB RTD # 12 Max. Temperature -50 250 1
o
CF4 0
03EC Reserved
... ...
03EF Reserved
03F0 RTD # 1 Max. Temperature (in Fahrenheit) -58 482 1
o
FF4 32
03F1 RTD # 2 Max. Temperature (in Fahrenheit) -58 482 1
o
FF4 32
03F2 RTD # 3 Max. Temperature (in Fahrenheit) -58 482 1
o
FF4 32
03F3 RTD # 4 Max. Temperature (in Fahrenheit) -58 482 1
o
FF4 32
03F4 RTD # 5 Max. Temperature (in Fahrenheit) -58 482 1
o
FF4 32
03F5 RTD # 6 Max. Temperature (in Fahrenheit) -58 482 1
o
FF4 32
03F6 RTD # 7 Max. Temperature (in Fahrenheit) -58 482 1
o
FF4 32
03F7 RTD # 8 Max. Temperature (in Fahrenheit) -58 482 1
o
FF4 32
03F8 RTD # 9 Max. Temperature (in Fahrenheit) -58 482 1
o
FF4 32
03F9 RTD # 10 Max. Temperature (in Fahrenheit) -58 482 1
o
FF4 32
03FA RTD # 11 Max. Temperature (in Fahrenheit) -58 482 1
o
FF4 32
03FB RTD # 12 Max. Temperature (in Fahrenheit) -58 482 1
o
FF4 32
03FC Reserved
... ...
03FF Reserved
ANALOG 0400 Analog I/P 1 Minimum -50000 50000 1 - F12 0
INPUTS 0402 Analog I/P 1 Maximum -50000 50000 1 - F12 0
MIN / MAX 0404 Analog I/P 2 Minimum -50000 50000 1 - F12 0
0406 Analog I/P 2 Maximum -50000 50000 1 - F12 0
0408 Analog I/P 3 Minimum -50000 50000 1 - F12 0
040A Analog I/P 3 Maximum -50000 50000 1 - F12 0
040C Analog I/P 4 Minimum -50000 50000 1 - F12 0
