6. COMMUNICATIONS MEMORY MAP
6-38
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
TYPES 1781 Bearing RTD Type 0 3 1 - FC120 0
1782 Ambient RTD Type 0 3 1 - FC120 0
1783 Other RTD Type 0 3 1 - FC120 0
1784 Reserved
...
178F Reserved
RTD #1 1790 RTD #1 Application 0 4 1 - FC121 1
1791 RTD #1 Alarm 0 2 1 - FC115 0
1792 RTD #1 Alarm Relays 0 6 1 - FC113 0
1793 RTD #1 Alarm Temperature 1 250 1
o
C F1 130
1794 RTD #1 Alarm Events 0 1 1 - FC103 0
1795 RTD #1 Trip 0 2 1 - FC115 0
1796 RTD #1 Trip Voting 1 12 1 - FC122 1
1797 RTD #1 Trip Relays 0 3 1 - FC111 0
1798 RTD #1 Trip Temperature 1 250 1
o
C F1 155
1799 1st and 2nd char. of RTD #1 Name 0 65535 1 - F22 ‘ ‘
...
179C 7th and 8th char. of RTD #1 Name 0 65535 1 - F22 ‘ ‘
179D Reserved
...
17AD Reserved
17AE RTD #1 Alarm Temperature (in Fahrenheit) 34 482 1
o
F F1 266
17AF RTD #1 Trip Temperature (in Fahrenheit) 34 482 1
o
F F1 311
RTD #2 17B0 RTD #2 Application 0 4 1 - FC121 1
17B1 RTD #2 Alarm 0 2 1 - FC115 0
17B2 RTD #2 Alarm Relays 0 6 1 - FC113 0
17B3 RTD #2 Alarm Temperature 1 250 1
o
C F1 130
17B4 RTD #2 Alarm Events 0 1 1 - FC103 0
17B5 RTD #2 Trip 0 2 1 - FC115 0
17B6 RTD #2 Trip Voting 1 12 1 - FC122 2
17B7 RTD #2 Trip Relays 0 3 1 - FC111 0
17B8 RTD #2 Trip Temperature 1 250 1
o
C F1 155
17B9 1st and 2nd char. of RTD #2 Name 0 65535 1 - F22 ‘ ‘
...
17BC 7th and 8th char. of RTD #2 Name 0 65535 1 - F22 ‘ ‘
17BD Reserved
...
17CD Reserved
17CE RTD #2 Alarm Temperature (in Fahrenheit) 34 482 1
o
F F1 266
17CF RTD #2 Trip Temperature (in Fahrenheit) 34 482 1
o
F F1 311
RTD #3 17D0 RTD #3 Application 0 4 1 - FC121 1
17D1 RTD #3 Alarm 0 2 1 - FC115 0
