Multilin SR469 - Page 185

6. COMMUNICATIONS MEMORY MAP
6-37
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
16AB Intentional GF Trip Delay 0 1000 10 ms F1 0
16AC Ground Fault Trip Backup 0 1 1 - FC103 0
16AD Ground Fault Trip Backup Relays 0 2 1 - FC119 0
16AE Ground Fault Trip Backup Delay 10 2000 10 ms F1 200
... Reserved
16BF Reserved
PHASE 16C0 Phase Differential Trip 0 2 1 - FC115 0
DIFFERENTIA
L
16C1 Phase Differential Trip Relays 0 6 1 - FC118 0
16C2 Differential Trip Pickup While Starting 5 100 1 x CT F3 10
16C3 Differential Trip Delay While Starting 0 60000 10 ms F1 0
16C4 Differential Trip Pickup While Running 5 100 1 x CT F3 10
16C5 Differential Trip Delay While Running 0 1000 10 ms F1 0
16C4 Reserved
...
16CF Reserved
ACCELERATIO
N
16D0 Acceleration Timer Trip 0 2 1 - FC115 0
TIMER 16D1 Acceleration Timer Trip Relays 0 3 1 - FC111 0
16D2 Acceleration Timer from Start 10 1000 1 s F2 100
16D3 Reserved
...
16DF Reserved
START
INHIBIT
16E0 Start Inhibit Block 0 1 1 - FC103 0
16E1 Thermal Capacity Used Margin 0 25 1 % F1 25
16E2 Reserved
...
16EF Reserved
JOGGING 16F0 Jogging Block 0 1 1 - FC103 0
BLOCK 16F1 Maximum Starts/Hour Permissible 1 5 1 - F1 3
16F2 Time Between Starts 0 500 1 min F1 10
16F3 Reserved
...
16FF Reserved
RESTART 1700 Restart Block 0 1 1 - FC103 0
BLOCK 1701 Restart Block Time 1 50000 1 s F1 1
1702 Reserved
...
177F Reserved
RTD 1780 Stator RTD Type 0 3 1 - FC120 0
