6. COMMUNICATIONS MEMORY MAP
6-36
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
JAM 1661 Mechanical Jam Trip Relays 0 3 1 - FC111 0
1662 Mechanical Jam Pickup 101 300 1 x FLA F3 150
1663 Mechanical Jam Delay 1 30 1 s F1 1
1664 Reserved
...
166F Reserved
UNDER- 1670 Block Undercurrent from Start 0 15000 1 s F1 0
CURRENT 1671 Undercurrent Alarm 0 2 1 - FC115 0
1672 Undercurrent Alarm Relays 0 6 1 - FC113 0
1673 Undercurrent Alarm Pickup 10 95 1 x FLA F3 70
1674 Undercurrent Alarm Delay 1 60 1 s F1 1
1675 Undercurrent Alarm Events 0 1 1 - FC103 0
1676 Undercurrent Trip 0 2 1 - FC115 0
1677 Undercurrent Trip Relays 0 3 1 - FC111 0
1678 Undercurrent Trip Pickup 10 99 1 x FLA F3 70
1679 Undercurrent Trip Delay 1 60 1 s F1 1
167A Reserved
...
167F Reserved
CURRENT 1680 Current Unbalance Alarm 0 2 1 - FC115 0
UNBALANCE 1681 Current Unbalance Alarm Relays 0 6 1 - FC113 0
1682 Current Unbalance Alarm Pickup 4 40 1 % F1 15
1683 Current Unbalance Alarm Delay 1 60 1 s F1 1
1684 Current Unbalance Alarm Events 0 1 1 - FC103 0
1685 Current Unbalance Trip 0 2 1 - FC115 0
1686 Current Unbalance Trip Relays 0 3 1 - FC111 0
1687 Current Unbalance Trip Pickup 4 40 1 % F1 20
1688 Current Unbalance Trip Delay 1 60 1 s F1 1
1689 Reserved
...
169F Reserved
GROUND 16A0 Reserved
FAULT 16A1 Ground Fault Alarm 0 2 1 - FC115 0
16A2 Ground Fault Alarm Relays 0 6 1 - FC113 0
16A3 Ground Fault Alarm Pickup 10 100 1 x CT F3 10
16A4 Alarm Pickup for Multilin CT 50 / .025 25 2500 1 A F3 100
16A5 Intentional GF Alarm Delay 0 1000 10 ms F1 0
16A6 Ground Fault Alarm Events 0 1 1 - FC103 0
16A7 Ground Fault Trip 0 2 1 - FC115 0
16A8 Ground Fault Trip Relays 0 6 1 - FC118 0
16A9 Ground Fault Trip Pickup 10 100 1 x CT F3 20
16AA Trip Pickup for Multilin CT 50 / .025 25 2500 1 A F3 100
