Multilin SR469 - Page 183

6. COMMUNICATIONS MEMORY MAP
6-35
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
15D8 Time to Trip at 5.00 x FLA 5 999999 1 s F10 146
15DA Time to Trip at 5.50 x FLA 5 999999 1 s F10 120
15DC Time to Trip at 6.00 x FLA 5 999999 1 s F10 100
15DE Time to Trip at 6.50 x FLA 5 999999 1 s F10 85
15E0 Time to Trip at 7.00 x FLA 5 999999 1 s F10 73
15E2 Time to Trip at 7.50 x FLA 5 999999 1 s F10 63
15E4 Time to Trip at 8.00 x FLA 5 999999 1 s F10 56
15E6 Time to Trip at 10.0 x FLA 5 999999 1 s F10 56
15E8 Time to Trip at 15.0 x FLA 5 999999 1 s F10 56
15EA Time to Trip at 20.0 x FLA 5 999999 1 s F10 56
15EC Reserved
...
15FF Reserved
1600 Minimum Allowable Line Voltage 70 95 1 % Rated F1 80
1601 Stall Current at Min Vline 200 1500 1 x FLA F3 480
1602 Safe Stall Time at Min Vline 5 9999 1 s F2 200
1603 Accel. Intersect at Min Vline 200 1500 1 x FLA F3 380
1604 Stall Current at 100 % Vline 200 1500 1 x FLA F3 600
1605 Safe Stall Time at 100 % Vline 5 9999 1 s F2 100
1606 Accel. Intersect at 100 % Vline 200 1500 1 x FLA F3 500
1607 Reserved
...
163F Reserved
SHORT 1640 Short Circuit Trip 0 2 1 - FC115 0
CIRCUIT 1641 Overreach Filter 0 1 1 - FC103 0
TRIP 1642 Short Circuit Trip Relays 0 6 1 - FC118 0
1643 Short Circuit Trip Pickup 20 200 1 x CT F2 100
1644 Intentional Short Circuit Trip Delay 0 1000 10 ms F1 0
1645 Short Circuit Trip Backup 0 1 1 - FC103 0
1646 Short Circuit Backup Relays 0 2 1 - FC119 0
1647 Short Circuit Trip Backup Delay 10 2000 10 ms F1 200
1648 Reserved
...
164F Reserved
OVERLOAD 1650 Overload Alarm 0 2 1 - FC115 0
ALARM 1651 Overload Alarm Relays 0 6 1 - FC113 0
1652 Overload Alarm Events 0 1 1 - FC103 0
1653 Overload Alarm Delay 1 600 1 s F2 0
1654 Reserved
...
165F Reserved
MECHANICAL 1660 Mechanical Jam Trip 0 2 1 - FC115 0
